FOR YOUR SAFETY

WARNING: BE SURE THE ELECTRICITY TO THE WIRES

YOU ARE WORKING ON IS SHUT OFF; EITHER THE FUSE IS

REMOVED OR THE CIRCUIT BREAKER IS SHUT OFF.

GENERAL

You don’t need special tools to install this xture. Be sure to follow

the steps in the order given. Under no circumstances should a

xture be hung on house electrical wires, nor should a swag type

xture be installed on a ceiling which contains a radiant type heating

system. Read instructions carefully. If you are unclear as to how to

proceed, consult a qualied electrician.

NOTE: Proper wiring is essential for the safe operation of this xture.

FIXTURE ASSEMBLY

Carefully remove the xture from the carton and check that all parts

are included as shown in gure. Be careful not to misplace any of

the screws or parts, which are needed to install this xture.

STEP 1: Thread tube. Carefully pass the wires through each tube

during assembly. Repeat this step until the desired hanging height

is reached.

STEP 2: Thread the tube into the canopy and body.

INSTALLATION

IMPORTANT: Do not attach xture directly to outlet box.

STEP 1: Thread mounting screw into the matching hole of cross bar.

STEP 2: Secure the cross bar to outlet box with outlet box screws.

GROUNDING INSTRUCTIONS

STEP 1: Insert the green grounding screw into the hole with two

raised dimples on the mounting bar. Wrap the ground wire from the

xture (if supplied) around the green grounding screw, then connect it

to ground wire from the outlet box (if not xed on the outlet box) using

a wire connector (not supplied). If ground wire from the xture is not

supplied, wrap the ground wire (if not xed on the outlet box) from the

outlet box around the green grounding screw and tighten it.

NEVER CONNECT GROUND WIRE TO BLACK OR WHITE

POWER SUPPLY WIRES.

STEP 2: Take note of the color of the wire(s) on your xture. Identify

which group your xture wire(s) falls into and connect the wires

according to the directions below:

GROUP A:

Connect to Black House Wire

GROUP B:

Connect to White House Wire

BLACK WHITE

* PARALLEL WIRE (round & smooth) * PARALLEL WIRE (square & ridged)

WHITE OR GREY WITH TRACER WHITE OR GREY WITHOUT TRACER

BROWN, GOLD OR BLACK

WITHOUT TRACER

BROWN, GOLD OR BLACK

WITH TRACER

NOTE: When parallel wire (SPT-I & SPT-2) is used, the tracer wire is

square shaped or ridged and the less tracer wire is round in shape

or smooth (seen best when viewed from wire end.)

STEP 3: Take your xture wire(s) from group A and place evenly

against the black wire from the outlet box. Do NOT twist wires

together before using wire connectors.

STEP 4: Fit a wire connector over the wires and screw the

connector clockwise until you feel rmness.

STEP 5: Try gently to pull the connector off the wires. If you can

pull the connector off, carefully re-do steps 3 and 4 as above, and

check again for a rm connection.

STEP 6: Connect the xture wire from group B to the white wire

from the outlet box in the same manner. Make sure no bare wires

can be seen outside wire connectors.

FINAL ASSEMBLY

STEP 1: After wires are connected, tuck them carefully inside outlet

box. Raise canopy allowing the mounting screw to protrude through

the hole in the canopy, and secure with ball nuts.

STEP 2: Secure glass with socket ring.

STEP 3: Install lamp (not included). Do not exceed the maximum

capacity recommended on the socket.

CLEANING

To clean, wipe xture with a soft cloth. Clean glass with a mild soap.

Do not use abrasive materials such as scouring pads or powders,

steel wool or abrasive paper.

ORDERING PARTS

Keep this sheet for future reference, and in case you need to order

replacement parts. Be sure to use exact wording from illustration

when ordering parts.

Line art shown may not exactly match the xture enclosed. However, the installations

do apply to this xture.

La ilustración puede no concordar exactamente con la pieza enviada. Sin embargo,

las instalaciones sí aplican para esta pieza.

Les images peuvent ne pas correspondre exactement au luminaire de la boîte.

Par contre, les directives d’installation s’appliquent au luminaire.

ITEM NO: 60-8064

ARTÍCULO Nº: 60-8064

ARTICLE N°: 60-8064

INSTALLATION AND SAFETY INSTRUCTIONS

FIGURE
