Side 1/2
2X250 LUMEN
RECHARGEABLE LED
FLOOD/SPOT HEAD LAMP
PHLR225D
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND
OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT.
Failure to follow all instructions listed below may result in electric
shock, fire and/or serious personal injury.
WARNING:
Do Not shine the LED light directly into the eyes of others.
Do Not allow children to use LED light unless under the
supervision of an adult.
WARNING: This head lamp is powered by a Lithium-
ion battery. Lithium-ion batteries are small, compact and ideal for
providing long-lasting power to this product. However they must
be used and charged properly. Improper use can result in serious
injury, fire or death.
CAUTION: This product comes with the battery installed
internally. Do not attempt to remove the battery from the product.
• Do not place this lithium-ion battery powered product in fire or
apply heat to it.
• Do not apply strong impact or shocks to this lithium-ion battery
powered product.
• Do not allow the lithium-ion battery to get wet.
• Do not leave this lithium-ion battery powered product in the
direct sunlight, or use or store it inside cars in hot weather.
Doing so may cause the battery to generate heat, rupture, or
ignite. Using the battery in this matter may also result in a loss
of performance and a shortened battery life.
• NEVER THROW WATER ON A BURNING LITHIUM-ION BATTERY! If
a lithium-ion battery does catch on fire, it will burn even more
violently when contacted with water. Use a fire extinguisher.
• Store the product at temperatures between 41°F and 77°F (5°C
and 25°C).
• Properly dispose of all batteries at a recycling center or per local
code. More information regarding battery disposal in U.S. and
Canada is available at; http://www.rbrc.org/index.html, or by
calling 1-800-822-8837 (1-800-8BATTER).
SPECIFICATIONS
Brightness for Spot Light: 250 Lumens Max
Brightness for Flood Light: 250 Lumens Max
Power: 3.7V Rechargeable Lithium-Ion Battery, 750mAh
Beam Distances: 377 Feet (Spot Light), 65 Feet (Flood Light)
Beam Angles: 10° (Spot Light), 120° (Flood Light)
Modes: High-Low-Flashing
Run Time: 3-8 Hours
Charge Time: 4-5 Hours
Net Weight: 2.8 oz
Includes: Head Lamp, USB charging cable and Operator’s Manual
CHARGING THE BATTERY (FIG 2)
The head lamp can be recharged by connecting the included USB
charging cable to a USB power output, a cellular phone power
adaptor or a laptop USB port for example.
1. Make sure the head lamp is turned off.
2. Lift the port cover (7) to expose the charging port.
3. Connect the Micro end of the charging cable to the charging
port (5).
4. Connect the USB end of the charging cable to a USB power
output.
5. The LED indicator (6) will be illuminating RED, indicating
charging is in progress.
6. The LED indicator turns GREEN when the charging is
completed.
OPERATING INSTRUCTIONS
Switch Actions
There are two switch buttons. Switch Button
A
(1-FIG 1) controls
the flood lights. Switch Button
B
(2-FIG 1) controls the spot light.
• Press
A
to turn on the flood lights.
• Press
A
continuously to rotate the flood light mode in follow-
ing sequence: High-Low-Flashing-Off.
• Press
A
to turn the flood lights off if one of the working modes-
High, Low or Flashing- has been on for more than 10 seconds.
• Press
B
to turn on the spot light.
• Press
B
continuously to rotate the spot light mode in the
following sequence: High-Low-Flashing-Off.
• Press
B
to turn the spot light off if one of the working modes-
High, Low or Flashing- has been on for more than 10 seconds.
WARRANTY
This product is warranted free from defects in material and workmanship
for 2 (Two) years after date of purchase. This limited warranty does not
cover normal wear and tear or damage from neglect or accident. The
original purchaser is covered by this warranty and it is not transferable.
Prior to returning your product to store location of purchase, please call
the Toll-Free Help Line for possible solutions.
ACCESSORIES And BAttERIES InCLUdEd In tHIS KIt ARE nOt
COVEREd BY tHE 2 YEAR WARRAntY.
TOLL FREE HELP LINE:
888-552-8665
powersmithproducts.com
Operator’s Manual
FIG 1
4
1
3
4
2
1. Switch Button A
2. Switch Button B
3. Spot LED Light
4. Flood LED Lights
FIG 2
5
6
7
