VSP V E- - -2001A

Issue 4

1 947218

V E- -2001A

SINGLE ZONE (PLUS) PAGE CONTROL UNIT

INTRODUCTION

The V- -2001A E Page Control Unit is manufactured by

Valcom, Inc.

The V- -2001A E provides telephone system access to

a single zone of one-way paging.

"WARNING: To reduce the risk of fire or

electric shock, do not expose this equipment

to rain or moisture."

"WARNING: Shock Hazard - Do Not Open."

"AVIS: Risque de Choc Electrique ne pas

Ouvrir."

"PELIGRO: Corriente Electrica - No Abra."

“CAUTION: To reduce the risk of fire replace

only with same type 1A, 125V fuse. 1A, 125V

may be replaced by a 0.5A, 250V provided

voltage selector is set for 230V.”

“DANGER: Afin de réduire le risque de feu,

remplacez le fusible par le même type de

fusible à 1A, 125V. On peut utiliser un fusible

à 0.5A, 250V pourvu que le sélecteur

dalimentation soit fixé sur 230V. Ne pas

ouvrir.”

“VORSICHT: Zur verringerung von

feuergefahr die sicherung nur mit derselben

type 1A, 125V ersetzen. Statt 1A, 125V Kann

0.5A, 250V Benutzt werden, vorausgesetzt, die

spannung ist auf 230V eingestellt. Nicht

öffnen.”

“PELIGRO: Para reducir el peligro de

incendio remplazarlo unicamente con un

fusible del mismo tipo 1A, 125V. El fusible de

1A, 125V podra ser remplazado por uno de

0.5A, 250V si el selector de voltaje esta puesto

en 230V. No abres.”

SPECIFICATIONS

Access Methods

• Electronic Key System (C. O. Line Position)

• PABX (Loop or Earth Call Trunk Port)

1A2 Key Systems (400 type line card required)

• 600 Ohm Page Port

• Stand Alone Handset(s) (Used for access of the

V- -2001A E only)

Features

• Page override capability (Using C. O. line

position or loop start trunk port)

• Switchable battery feed for loop start operation

• RJ11 for "A" and "B" connections

• AGC on all voice outputs

• Provides audio for up to 150 Valcom one-way

amplified speaker assemblies

• Background music input

• Voice operated VOX to mute music during page

• Optional contact closure activation

• Easily accessible music and tone volume controls

• Removable screw terminal connectors provided

• Supplies 20 Valcom power units

(1 Amp -24VDC) for powering speaker amplifier

assemblies

• Page with music outputs (2 provided) music

mutes during page

• Page without music output

• Time clock/single tone (Contact closure

activated)

• Night ring/warble tone

(Closure or 90VAC activated)

Priority sequence of tones:

Page overrides music

Night ring mixes with music and page

Time clock mixes with music and page

• Individual switches for selection of night ring

and time clock tones per output

• May be used with 25 or 70 Volt amplifiers

• AC powered, 230 or 115VAC

• Internationally recognized power connector

• AC input fused at 0.5 Amp @ 230VAC, 50 Hz or 1

Amp @ 115VAC, 60 Hz

• 115/230 Volt selector switch for international use

• UL listed

Dimensions/Weight

• 7.10" H x 9.00" W x 2.40" D

(18.03cm H x 22.86cm W x 6.10cm D)

• 3.7 lbs. (1.68kg)

Nominal Specifications

Input Impedance: 600 Ohms

Input Level: -10dBm nominal

Voice Switch Sensitivity: -21dBm

Music Source Input Impedance: 8 to 600 Ohms

Music Input Level: -10dBm nominal

Output Impedance: 8 Ohms

Output Level: -10dBm nominal

DC Output: 1 Amp at -24VDC

Nominal Power Requirements

Voltage: Current:

230VAC 0.5 Amp

115VAC 1 Amp

The V- - -2001A E is equipped with a standard 3 prong

polarized MOLEX connector to allow connection of a

battery backup supply in case of AC power failure.

• Use a cord set consis ting of a minimum 18 AWG

cord and grounding type attachment plug rated a

minimum of 15A, 250V. The cord set should have

the appropriate safety approvals for the country

in which the equipment will be installed and

should be marked HAR.

• The socket outlet shall be installed near the

equipment and shall be easily accessible.

Environment

Temperature: 0 to 40 Degrees C

Humidity: 0 to 85% non-precipitating

INSTALLATION

NOTE: The telephone system referred to in this

manual is the customer premise equipment such

as an electronic key system, a PABX or a

dedicated single line telephone set(s). The

V- -2001A E is not intended for direct or indirect

connection to the public telephone network or to

PABX analog station ports. When used with a

customer premise telephone system such as a

key system or PABX system, these units are

interfaced to the system via a fully protected page

port or system central office port, which is a fully

protected interface device. Also, the host system

must be configured to disallow central office

trunk conferencing in order to prevent indirect

connection to the public network.

Precautionary Designations

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Mounting

The V- -2001A E was designed for wall or table

mounting. Secure unit to wall studs or a suitable

brace away from heat sources or strong magnetic

fields (Motors, fans, power supplies, etc.) with the

control and terminal strip accessible. Four wood

screws are included for mounting.
