Ford

2004 – 4 F150 201

2008 – 2014 F250 / F350

- Specially designed for the Ford F1 truck for an OEM l k. 50 oo

- 170 degree wide view angle for excellent visibility.

- Super CMOS technology provides a sharper picture day and night.

- Minimum illumina on 0.1 lux.

Tailgate Handle Ca ra Assembly 20 Ft. Cable me

1 / 2

Green wire (B)*

26 Ft. Coax Cable

Green wire (B)*

Ground (Black wire)

RED wire (A)*

To Aftermarket Radio

Backup Camera Input

Reverse Camera Interface

Backup Camera Input

WHITE Wire

Parking Guideline

(ON / OFF see next page)

Green wire (A)*

* NOTE:The camera needs a +12V trigger. Power the camera from the reverse light wire using RED Wire A. GREEN Wire

rev. 080722

1. Start by lowering the tailgate of the truck. Remove the tailgate cover by using a T-30 torx bit, remove

(8-13 depending on the model) torx bolts that secure the tailgate cover.

2. After removing the tailgate cover you wi have access to the backside of the factory tailgate handle. ll

Using a 10mm socket, remove the (2) nuts holding the tailgate handle in place. Lift up on the latch to

release the (2) ta gate handle studs and remove the tailgate handle. il

3. On the lock cyli

nder, remove the metal clip that holds the locking mechanism in place. Re-Install the

locking mechanism onto the new ta gate handle. il

4. Re-assemble the new tailgate handle into the tailgate in reverse order. Route the wiring to power the

camera towards the bott of the tailgate and through an access port to reach underneath the truck. om

5. Route the Video and Power cables from the tailgate of the truck towards the radio location where the

rest of the installation of the camera will take place. Th

e CFD-03F camera cable has 2 GREEN wires

used to power the camera. GREEN wire A is located closer to the camera. GREEN wire B is located

Test the camera before completely instal ng the radio.li

TROUBLESHOOTING:

If camera is not turning on, please use source ground instead of chassis ground for the black ground wire.

Tip: There should be an opening between the cabin and the bed of the truck where you can insert the

cables into the cabin area.

rev. 080722

2 / 2

Near the RCA.

For Aftermarket radio and reverse camera interface installations, tap power to GREEN Wire B (Near RCA)

and connect GREEN wire B (Pass through wire) to the RED wire. Tap BLACK Wire to an existing

An alternative method to power the camera is through +12V reverse light wire in the tail light assembly.

You can tap the thin RED wire, coming from the regulator to the +12V reverse light wire in the tail light

assembly. Make sure to insulate with tape BOTH GREEN WIRES that are not being used to avoid a

short circuit.

ground lead or vehicle body chassis.
