Canopy

1ea

Mounting

Screws

2ea Top loop 1ea

Chain 6ft Wire connectors 3ea Bottom cap 1ea

Chain connector

2ea

Canopy loop

and Canopy

loop collar

1ea Nipple 2ea

Mounting Strap 1ea Hex Nut 2ea Finial 1ea

Part Needed Quantity

Reason why ( missing, scratched, broken glass, bent, bad nish)

Comments

F A IIXTURE SSEMBLY NSTRUCTIONS

For Customer Service, contact the place of purchase to arrange for replacement parts.

NOTE: INSTALL THE GLASS ASSEMBLY

AFTER THE FIXTURE IS HUNG.

1. Thread the Body (L) onto the Coupling (M) and

until tight.

2. Then screw the Top Loop (J) to the threaded

Nipple (K) at top of Frame until tight.

8106-3P CDB

Read and review installation instruction sheet before

assembling the xture.

Fig 1

PARTS & ASSEMBLY SHEET

This xture assembled PO:__________ Date: ________

Fixture Name: Torbellino 8106-3P CDB

Notice: Please review the parts listing and check for all parts before assembling the xture. If any parts are

missing or damaged, please note onthis sheet and contact the place of purchase to arrange for

replacement parts.

PARTS LIST

Company Name:_______________________Co. Account #:_____________

to be lled out by retailer

For Customer Service, contact the place of purchase to arrange for replacement parts.

3. By measuring determine correct number of links

needed for proper hanging height. Use a pair of

pliers to open one link of the Chain (C2) then

remove the excess Chain (C2) and discard it.

4. Use one chain connector(E2) to attach one end of

the chain to the Top loop (D2) and close the chain

connector.

5. Feed the xture wires through the Chain (every

three links) and pull the wires until taut.

6. Slip Canopy loop collar (B2) over the chain, then

do the same with the canopy (F2).

7. When ready to complete the installation Use the

other chain connector and attach the other end of

the chain to the canopy loop (A2) and close the

chain connector.

8. Make sure the weight of the chandelier is

supported by the chain-not the electrical wire.

* You may now install the xture.

Fig 2

PARTS & ASSEMBLY SHEET

Fixture Name: Torbellino 8106-3P CDB

NOTE: Complete these remaining steps after the

xture is hung.

9. Thread the Nipple (P) into the Coupling (N), and

then thread the Hex Nut (Q) onto Nipple (P) until

tight.

10. Install the light bulbs in accordance with the

xture’s specications.

11. Place Glass Shade (R) over the Metal Ring .

The Nipple (P) shall protrude through the bottom

hole of the Glass Shade (R).

12. While holding the Glass Shade slide the

13. Slide Bottom Cap (U) over Nipple (P) and thread

the Finial (V) until tight.

(DO NOT EXCEED THE MAXIMUM WATTAGE

RATING)

Fig 3

CHAIN
