Side 1/60

PUBLIC ADDRESS

AMPLIFIER

Installation and User Instructions

For models:

• HQ-HA30W

WARNING:THIS APPLIANCE MUST BE EARTHED

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT

The wires in the mains lead are coloured

in accordance with the following code:

GENERAL INSTALLATION

DO NOT run microphone cables near mains, data, telephone or 100V line cables.

DO NOT run 100V line cables near data, telephone or other low voltage cables.

DO NOT exceed 90% of the amplifiers output power when using 100V line (speech only).

DO NOT exceed 70% of the amplifiers output power when using 100V line (high level

background music).

DO NOT use re-entrant horn loudspeakers for background music unless the loudspeaker has

been specifically designed for this purpose.

AVOID jointing the microphone cable, when this is unavoidable make sure a good screened

connector is used, e.g. XLR.

ALWAYS use a balanced or floating low impedance microphone terminating into a balanced

input on long microphone cable runs.

ALWAYS use a mains grade double insulated cable for the loudspeaker cable runs.

ENSURE that all loudspeakers are in-phase.

ENSURE that there are no short circuits on the loudspeaker line before connecting to the

amplifier.

Green and Yellow: Earth (E)

Blue: Neutral (N)

Brown : Live (L)

As the colours of the wires in the mains lead of this

appliance may not correspond with the coloured markings

identifying the terminals in your plug proceed as follows:

• The green and yellow coloured wire must be

connected to the terminal that is marked by the letter E,

marked by the safety earth symbol or coloured green

and yellow.

• The blue coloured wire must be connected to the

terminal that is marked with the letter N or coloured

black.

• The brown coloured wire must be connected to the

terminal that is marked with the letter L or coloured red.

If a 13 Amp (B.S.1363) plug or any other type of plug is

used,a 5 Amp fuse must be fitted either in the plug or at the

distribution board.

Produkt Specifikationer

Mærke:	HQ
Kategori:	Modtager
Model:	HA30W
Vekselstrømsindgangsspænding:	230 V
Bredde:	430 mm
Dybde:	300 mm
Højde:	88 mm
Brugervejledning:	Ja
Produktfarve:	Sort
Indbygget skærm:	Ingen
Pakkevægt:	6740 g
Udgangseffekt (RMS):	30 W
Hurtig start guide:	Ja
Frekvensområde:	30 - 17000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	- kanaler
Pakkens dimensioner (BxDxH):	350 x 510 x 175 mm
Formål:	Hjem
DC indgangsspænding:	24 V
klirfaktor (THD):	1 %
Signal/støjforhold:	- dB
Spidseffekt pr. kanal:	- W
Output impedans:	8 ohm (Ω)
