Side 1/4
RP4-GM32
Radio Replacement & Steering Wheel Control Interface
for General Motors Vehicles
Pacic Accessory Corporation
® | Clearwater, Florida 33760 | Ph. 866-931-8021 | support@pac-audio.com
©2015 Pacic Accessory Corporation
www.pac-audio.com
Rev. 012115
C
Introduction & Features
Important Notes
Wiring Connection Chart
Illustration / Schematic
The RP4-GM32 interface allows the replacement of a factory radio in select General Motors vehicles with 29-bit LAN
radios. Using this interface will retain factory features such as steering wheel controls (SWC), Warning Chimes, Rear
Seat Controls (RSC) and the BOSE amplier when the original radio is removed. Use of this interface also allows you
to program two radio functions to each SWC button by using short press long press dual command functionality. The
RP4-GM32 also provides data bus driven outputs such as retained accessory power (RAP), vehicle speed sensor (VSS),
illumination, reverse trigger and parking brake.
1. The radio select rotary switch on the side of the interface must be adjusted to the proper radio setting before plugging the
interface into the vehicle (see below for setting chart).
2. The interface comes pre-programmed for all of the vehicles factory SWC functions and does not require programming unless
you wish to re-assign the SWC functions or utilize short press long press dual command functionality. The SWC can always be
restored to default settings by pressing and releasing the program button on the side of the interface once and waiting 7 seconds
for the LED to ash 4 times.
3. RSC buttons that are identical to the SWC will mimic the SWC one for one.
4. The LED will ash whenever a SWC button is pressed.
Red / White Parking Brake
Output (-)
Purple / White Vehicle Speed
Output
Blue / White Amp Turn On Input
Red Accessory Output
Orange / White Illumination
Output (+)
Green Reverse Output (+)
Interface Connector
Yellow Battery +12v
Black Ground
Blue Antenna On Input
White Front L + input
White / Black Front L - input
Grey Front R + input
Grey / Black Front R - input
Green Rear L + input
Green / Black Rear L - input
Purple Rear R + input
Purple / Black Rear R - input
Vehicle Connector SWC Connector
Interface Connector
See above chart for
wire color descriptions.
Vehicle Connector
See above chart for
wire color description.
SWC Connection
See above chart for
different radio type
connections
Acc On/
Programming
LED
Programming
Button
Wiring SWC Connection
Page 1
Blue/Yellow Kenwood, Newer
JVC,
3.5mm Jack Alpine, JVC,
Clarion, Fusion,
Pioneer, Sony,
Boyo, Dual,
Lightning Audio,
Visteon or Advent
RP4-GM32
Radio Replacement & Steering Wheel Control Interface
for General Motors Vehicles
Pacic Accessory Corporation
® | Clearwater, Florida 33760 | Ph. 866-931-8021 | support@pac-audio.com
©2015 Pacic Accessory Corporation
www.pac-audio.com
C
Rev. 012115
Installation Steps
1.The radio select rotary switch on the side of the interface must be adjusted to the proper radio
setting before plugging the interface into the vehicle.
2. Make all connections as described in the chart on page 1. If there is a Bose® Audio system present: Connect the RCA inputs to the
aftermarket radios pre-amp output. The audio level will vary depending on the new radios pre-amp output voltage (2-4 volts is recommended).
If there is not a Bose® Audio system present: Cut the RCA inputs off and connect the aftermarket radios speaker outputs to the remaining
wire according to the chart on page 1.
3. Connect the SWC wire according to the chart on page 1 (aftermarket radio MUST support a wired remote input).
4. If you wish to reassign functions to the SWC follow the programming instructions in the next section.
Default SWC Button Assignments
Page 2
Alpine JVC Kenwood Clarion Sony/Pionee
r
Fusion
V
olume + Volume + Volume + Volume + Volume + Volume + Volume +
V
olume - Volume - Volume - Volume - Volume - Volume - Volume -
Source Source Source Source Source Source Source
Track + Track + Track + Track + Search + Track + Track +
Track - Track - Track - Track - Search - Track - Track -
V
oice Mute Mute Mute Mute Mute Mute
Play/Pause Preset + Preset/Disc - Disc/FM+ Band Preset +
A
udio
IMPORTANT! The interface comes pre-programmed for the functions listed in the chart below and does not require programming
unless you wish to re-assign the SWC functions to different buttons. The SWC can always be restored to default settings by
pressing the program button on the side of the interface once and waiting for the timeout.
Default Steering Wheel Control Programming
Optional Steering Wheel Control Programming
Alpine SonyJVC Kenwood Clarion Pioneer/Other Fusion
1 2 3 7 8 94
Other = Advent, BOYO, Dual, Lightning Audio, Rockford Fosgate, Visteon
SET RADIO SELECT SWITCH
If you wish to re-assign the SWC functions or utilize short press long press dual command functionality, the interface must be
programmed in the specic order shown on the chart below. If you come across a function in the chart that your steering wheel
does not have, or you do not want to program, press and release the programming button on the side of the interface to skip that
function. The LED will ash off and on conrming that you have successfully skipped that function and are ready to proceed to
the next one.
Short Press Long Press Dual Command Functionality
This feature allows you to assign two aftermarket radio functions to each of the vehicles SWC buttons. It can be used with as
many of the buttons as the user likes or none at all. When this functionality is implemented, quickly pressing and releasing a SWC
button will initiate the short press command while pressing and holding a SWC button for longer than two seconds will initiate the
long press command. Please note that no long press commands are programmed by default. If you wish to assign dual command
functionality to the SWC please follow the programming steps on the next page.
