SRK-GM14HX
Radio Replacement Kit for select
2014-2019 Silverado/Sierra Trucks
Stinger HEIGH10
© 2024 Stinger. All rights reserved. PAC is a Power Brand of Stinger Solutions.
Pacific Accessory Corporation
Page 1
Rev: V1
Date: 123024
®
Introduction and Features
The SRK-GM14HX is a complete radio replacement kit for the installation of the Stinger HEIGH10 (UN1810) modular radio in
Chevrolet Silverado and GMC Sierra trucks. All modules, cables and adapters are included to retain important features of the
factory system, including: OnStar, front and rear park assist, warning chimes, factory reverse camera, steering wheel-mounted
radio controls and AM/FM reception. Plug & Play wiring harnesses allow for quick and easy installation without the need to cut or
splice any wiring. The display mounting panel allows ush mounting the 10 inch display without modifying/cutting any part of the
vehicle’s sub-dash.
Important Notes
Recommended Tools
We recommend reading this manual thoroughly to familiarize yourself
with the entire process prior to beginning the installation.
1. Display Mounting Panel
2. Dual USB Extension (SSUSB3)
3. AM / FM Antenna Adapter (BAA22)
4. Main Harness Adapter (SR-SRK-ADAPT-UN1810)
5. Main Harness (SRK-GM14HX-HAR)
6. Vehicle Harness Adapter (GM52-ADAPT)
7. Radio Replacement Interface (GM6A-SRK)
8. Steering Wheel Control Harness (GM5LIN-SW-HAR)
9. Factory Rear Camera Adapter (CAM-GM51-HAR)
10. IOB Display Harness (GM5CAM-DIS-HAR)
11. MOST Loops (MOST Loop 1 / MOST Loop 2)
12. External Chime Speaker (RPA-SPK)
13. Dierential Video Adapter (RPA-VA1)
14. Satellite Antenna Adapter (SAT-01)
15. Side Mounting Brackets (L & R)
16. PAC-Link Cable (10P-2-10P-6)
17. PAC-Link Module (PL1)
Included Components
1
4
6
10
8
5
2
11
3
9
12
13
14
1. Does not retain the following factory features:
2. If installing aftermarket ampliers, the included RPA-SPK can be used to retain OnStar/chimes.
3. Chime volume can be adjusted in the HEIGH10’s settings
4. The Voice button can be set to activate the factory OnStar function when pressed for longer than 1.5 seconds or given the
ability to control the aftermarket radio. This option can be found in the Installer Settings on the HEIGH10. By default, this fea-
ture is set to control the aftermarket radio, but OnStar can still be accessed by using the mirror controls.
5. This guide is applicale to HEIGH10 (UN1810) radios. For ix210 (HORIZON10/HEIGH10+) radios, see the ix210 Installation
Guide
● Factory satellite radio
● Rear seat entertainment system (RSE)
● Time of Day in Cluster
● Factory USB Ports
Plastic Panel Tool
7mm Socket
10mm Socket
Pick Tool
Wire Feeder
Power Screwdriver
Ratchet
Torx T15 Screwdriver
Small Flat-blade Screwdriver
NOTE: Along with the SRK-GM14HX components,
additional hardware and wire harnesses from the HEIGH10
(UN1810) kit will also be used in the installation.
15
● Valet Mode
● Teen Driver Features
● OnStar Text
● Wi-Fi
7
16
17
SRK-GM14HX
Radio Replacement Kit for select
2014-2019 Silverado/Sierra Trucks
Stinger HEIGH10
© 2024 Stinger. All rights reserved. PAC is a Power Brand of Stinger Solutions.
Pacific Accessory Corporation
Page 2
Rev: V1
Date: 123024
®
GPS
USB1
USB2
STINGER
GRAY BLACK
24PIN
16PIN
GPS
ANT
Stinger ix210
Connections
SR-GM14HX
Connections
Connections shown are
all required for full
functionality of the kit
and radio. If adding
additional components,
additional connections
will be needed.
Connects to
SXV300 Satellite
Radio Tuner
(sold separately)
SSUSB3
REVERSE CAM IN
A/V IN
RPA-VA1
REVERSE CAM
AUX Audio
CAM GM51 INPUT
SWC INPUT
GM52-ADAPT SRK-GM14HX-HAR
CAM-GM51-HAR
GM5LIN-SW-HAR
16 Pin Radio
BAA22
SAT-01
GM6A-SRK
RadioPRO
ADVANCED
AMPLIFIEDNON-AMPLIFIEDVEHICLE HARNESS
EXPANSION
PORT
POWER
RADIO HARNESS
PAC-LINK
PL1
10P-2-10P-6
PAC Link (PL1)
UN1810
STEERING WHEEL
CONTROL
SPEED SEN
6PIN 10PIN
Wiring Overview
