Pelican 1920 LED Manual

Pelican Lommelygte 1920 LED

Læs gratis den danske manual til Pelican 1920 LED (2 sider) i kategorien Lommelygte. Denne vejledning er vurderet som hjælpsom af 12 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 6.5 anmeldelser. Har du et spørgsmål om Pelican 1920 LED, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

PELICAN

INSTRUCTION MANUAL

INTRODUCTION

This compact flashlight produces an ultra bright

light beam by using a LED powered by (2) two

AAA 1.5V alkaline batteries. The 1920 flashlight is

designed for easy use with one hand operation

and has a dual-switch mode for constant-on and

momentary-on. The 1920 flashlight body is made

by high precision CNC machines from

aircraft-grade aluminum alloy for the most durable

construction. The 1920 flashlight is water resistant.

TO INSERT BATTERIES

1. Remove the tail cap by turning counter-clockwise.

2. Install (2) two AAA alkaline batteries with

+ terminal facing to the head assembly.

3. Replace the tail cap onto the flashlight

by turning clockwise until sealed

OPERATION

1. CONSTANT-ON ----

Press the tail button to turn ON.

2. LIGHT-OFF ----

Press the tail button to turn OFF.

3. MOMENTARY ----

Gently depress the tail button for

momentary operation.

TO CHANGE BATTERIES

1. Remove the tail cap by turning

counter-clockwise until it comes off the

rear of the 1920 flashlight.

2. Remove the (2) two used batteries

from the 1920 flashlight.

3. Install the (2) two new AAA alkaline batteries

with + terminal facing to the head assembly.

4. Replace the tail cap by turning clockwise

until sealed.

GENERAL CARE AND

MAINTENANCE

1. Clean o-rings with a soft clean cloth to insure that

sealing area is free of dirt that could destroy the

o-ring seal.

2. Apply a light coat of clear silicone grease on the

o-rings occasionally if turning action becomes too

difficult.

3. Remove the tail cap and wipe the rear threads of

the 1920 flashlight body and inside of the tail cap

with a soft clean cloth occasionally to avoid

intermittent flashlight operation.

CAUTION

To prevent the 1920 flashlight coming on

accidentally when the flashlight is stored,

remove the batteries. If the 1920 flashlight is

turned on while it is in a container, the

flashlight can overheat and damage the

flashlight or the material of the surrounding area.

SPECIFICATIONS

BULB: LED

Batteries: (2) Two AAA alkaline or other

equivalent alkaline batteries

O-RING MAINTENANCE

Check closely for cuts, scratches, or otherwise

damaged o-ring or mating lens lip surface. Remove

any dirt or foreign matter from o-ring sealing surfaces.

Keep threads, o-ring groove and inside lip of lens

lubricated with silicone grease. See Warranty

information for replacement of o-ring.

Battery Safety Bulletin Alkaline Batteries

1. Hazardous location safety approvals for explosive

environments are only valid for the specified cell

type manufacturer and, where applicable, brand

names that are displayed on the flashlight and/or

instructions sheets that are supplied with the light.

2. The use of other battery technologies may reduce

the performance of the the flashlight. Always read

the battery manufacturers recommendations for

the appropriate use of the battery technology/

brand prior to using them in the flashlight.

3. When replacing the batteries:

a. Replace all the batteries at the same time.

b. Do not mix battery brands and old and new

batteries.

c. Always insert batteries correctly with regard

to polarity (+ and -) marked on the battery and

equipment.

4. Do not change batteries in a hazardous location.

5. Remove batteries from equipment if it is not to be

used for an extended period of time.

1920

Cat. #1920

1923-311-000 5-0974 Rev A

All trademarks are registered and/or unregistered trademarks

of Pelican Products, Inc., its subsidiaries and/or affiliates.

PELICAN

PRODUCTS

23215 Early Avenue • Torrance, California 90505 USA

Tel 310.326.4700 • FAX 310.326.3311 • www.pelican.com

PELICAN

CANADA

10221-184 St. • Edmonton, Alberta T5S 2J4

Tel 780.481.6076 • FAX 780.481.9586

PELI

PRODUCTS, S.L.U.

c/ Provença, 388, Planta 7 • 08025 • Barcelona, Spain

Tel: +34 934 674 999 • Fax: +34 934 877 393

PELICAN LEGENDARY FULL LIFETIME

GUARANTEE OF EXCELLENCE

Pelican Products, Inc. guarantees its lights for a lifetime against

breakage or defects in workmanship. This guarantee does not

cover the lamp or batteries (rechargeable or alkaline).

Pelican will either repair or replace any defective product,

at our sole option. THE REMEDIES HEREBY PROVIDED

SHALL BE THE EXCLUSIVE AND SOLE REMEDY OF THE

PURCHASER. TO THE EXTENT PERMITTED BY LAW, IN

NO EVENT SHALL PELICAN BE LIABLE FOR ANY INDIRECT,

PUNITIVE, INCIDENTAL OR CONSEQUENTIAL DAMAGES,

OR SPECIAL DAMAGES, REGARDLESS OF WHETHER A

CLAIM FOR SUCH DAMAGES IS BASED ON WARRANTY,

CONTRACT, NEGLIGENCE OR OTHERWISE. In no event

shall Pelican’s liability to the purchaser for damages hereunder

exceed the purchase price of the product in respect of which

damages are claimed.

To make a warranty claim, the purchaser must contact

Pelican Products, Inc. at 23215 Early Avenue, Torrance, CA

90505 or sales@pelican.com. Any warranty claims shall be

made by the purchaser as soon as practicable. The purchaser

must obtain a return authorization number from Pelican Customer

Service prior to returning any product.

In the event that Pelican determines that any returned product

is not defective, within the terms of this warranty, the purchaser

shall pay Pelican all costs of handling, transportation and repairs

at Pelican’s prevailing rates.

All warranty claims of any nature are barred if the ﬂashlight has

been altered, damaged or in any way physically changed, or

subjected to abuse, misuse, negligence or accident.

Some states do not allow the exclusion or limitation of

incidental or consequential damages, so the above limitation or

exclusion may not apply to you. This warranty gives you speciﬁc

legal rights, and you may have other rights which vary from state

to state.

Lifetime Guarantee does not cover Roto Molded

or AALG products.

Refer to www.pelican.com/warranty for full details.

LA LÉGENDAIRE GARANTIE D’EXCELLENCE

À VIE DE PELICAN.

Pelican Products, Inc., garantit ses éclairages pour toute la durée

de leur vie utile contre la casse et les défauts de fabrication.

Cette garantie ne couvre pas les ampoules ni les batteries

(alcalines ou rechargeables).

Pelican réparera ou remplacera tout produit défectueux, à

sa seule discrétion. LES RECOURS MENTIONNÉS ICI

CONSTITUENT LES SEULS RECOURS DE L’ACHETEUR.

DANS LA MESURE PERMISE PAR LA LOI,EN AUCUN

CAS PELICAN NE SERA TENU RESPONSABLE D’AUCUN

DOMMAGE IMMATÉRIEL, PUNITIF, ACCESSOIRE OU

INDIRECT NI D’AUCUN DOMMAGE PARTICULIER, QU’UNE

RÉCLAMATION POUR DE TELS DOMMAGES SE BASE

OU NON SUR UNE GARANTIE, UN CONTRAT, UNE

NÉGLIGENCE OU AUTRE. En aucun cas la responsabilité

de Pelican envers l’acheteur en cas de dommages ne sera

supérieure au prix d’achat

du produit pour lequel des dommages et intérêts sont réclamés.

Pour déposer une demande de prise en charge sous garantie,

l’acheteur doit contacter Pelican Products, Inc., à l’adresse

suivante : 23215 Early Avenue, Torrance, CA 90505, États-Unis,

ou envoyer un courrier électronique à l’adresse suivante :

sales@pelican.com. Toute demande de prise en charge sous

garantie sera déposée par l’acheteur dès que possible. Avant

de retourner tout produit, l’acheteur doit obtenir un numéro

d’autorisation de retour du Service Client de Pelican.

Au cas où Pelican considérerait qu’un produit retourné n’est

pas défectueux, selon les conditions de la présente garantie,

l’acheteur remboursera Pelican de tous les frais de manipulation,

transport et réparation aux taux en vigueur de Pelican.

Toute demande de prise en charge sous garantie, de quelque

nature que ce soit, sera refusée si la torche a été modifiée,

endommagée ou physiquement changée d’une façon ou d’une

autre ou encore sujette à un traitement abusif, une mauvaise

utilisation, une négligence ou un accident.

Certains États n’autorisent pas l’exclusion ou la limitation des

dommages accessoires ou indirects, de telle sorte que la

limitation ou l’exclusion mentionnée ci-dessus peut ne pas

s’appliquer dans votre cas.

La présente garantie vous donne des droits légaux spécifiques

et vous pouvez bénéficier d’autres droits, variables d’un État à

l’autre.

La garantie à vie ne couvre pas les produits rotomoulés ou AALG.

Pour obtenir des informations complètes, visitez le site

www.pelican.com/warranty.

LED

Produkt Specifikationer

Mærke:	Pelican
Kategori:	Lommelygte
Model:	1920 LED
Vægt:	60 g
Produktfarve:	Sort
Lampe type:	LED
Vandfast:	Ja
Batterier inkluderet:	Ja
Materiale:	Aluminium
Batteritype:	AAA
Antal understøttede batterier:	2
Lommelygte type:	Hånd lommelygte
Lysstråle afstand (maks.):	81 m
Lysstrøm:	67 lm
USB-drevet:	Ingen
Pærespænding:	3 V
