INSTALLATION INSTRUCTIONS

CREATING POSITIVE CUSTOMER EXPERIENCES

9531-041-001-01

ECM-D70T / ECM-D70T1.5

Elliptical Ceiling Dual Mount for 37˝ to 50˝ Flat Panels

ECM-D70T / ECM-D70T1.5

Page 2 Visit the Premier Mounts website at http://www.premiermounts.com Installation Instructions

Contact Premier Mounts with any questions:

(800) 368-9700

techsupport@mounts.com

Contents

Warning Statements

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS MUST BE READ AND

COMPLETELY UNDERSTOOD TO PREVENT PERSONAL INJURY AND PROPERTY DAMAGE. KEEP THESE

INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS

PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY

UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS,

DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR

IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE

PROPER SAFETY GEAR AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.

At least two qualied people should perform the assembly procedure. Personal injury and/or property damage can result

from dropping or mishandling the at-panel.

Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are

no electrical wires in the ceiling. Cutting or drilling into an electrical line may cause serious personal injury.

Make sure there are no water or natural gas lines inside the ceiling where the mount is to be located. Cutting or drilling into a

water or gas line may cause severe property damage or personal injury.

This product is intended for indoor use only. Use of this product outdoors could lead to product failure and/or serious

personal injury.

Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of

impact.

Weight Capacity

Maximum at-panel weight:

180lbs.

THE CEILING STRUCTURE MUST BE CAPABLE OF HOLDING

FIVE (5) TIMES THE WEIGHT OF THE FLAT PANEL AND

MOUNT. IF NOT, THEN THE CEILING STRUCTURE MUST BE

REINFORCED.

INSTALL THE MOUNT ACCORDING TO THE INSTRUCTIONS PROVIDED BY PREMIER MOUNTS. PERFORM ALL

STRUCTURAL REINFORCEMENTS BEFORE ATTACHING THE FLAT PANEL TO THE CEILING MOUNT. USE THE

APPROPRIATE LIFTING DEVICE WHEN LIFTING THE FLAT PANEL INTO PLACE.

Installation Tools. ...................................................................................................................................................... 3

Parts List................................................................................................................................................................... 3

Mounting Hardware. ................................................................................................................................................. 4

Features. 5 ..................................................................................................................................................................

Selecting the Appropriate Mounting Hardware. ........................................................................................... 7

Griplate™ Washer Installation. 8 ....................................................................................................................

Nylon Spacer Installation. 8 ............................................................................................................................

Flat-Panel Installation. 9 ..............................................................................................................................................

Cable Management. 10 ...............................................................................................................................................

Tilt Positioning. ....................................................................................................................................................... 11

Optional Mounting Congurations and Accessories. .............................................................................................. 11

Technical Specications. ........................................................................................................................................ 12

Warranty 13 .................................................................................................................................................................

Disclaimer. 13 ..............................................................................................................................................................

Produkt Specifikationer

Mærke:	Premier Mounts
Kategori:	Flad panel støtte
Model:	ECM-D70T
Bredde:	945 mm
Højde:	549 mm
Vægt:	24600 g
Produktfarve:	Sort
Monteringstype:	Loft
Hældningsvinkelområde:	-15 - 15 °
Rotationsvinkel:	360 °
Maksimal vægtkapacitet:	79.5 kg
Maksimal skærmstørrelse kompatibilitet:	46 "
Antal understøttede skærme:	2
Minimal skærmstørrelse kompatibilitet:	40 "
Montering interface kompatibilitet (min.):	200 x 200 mm
Montering interface kompatibilitet (maks.):	875 x 505 mm
