INSTALLATION INSTRUCTIONS

FLIP

Flip-Down LCD Mount

NORTH AMERICA

3130 East Miraloma Avenue

Anaheim, CA 92806 USA

USA and Canada –

Phone: 800-368-9700

Fax: 800-832-4888

EUROPE

Swallow House,

Shilton Industrial Estate,

Shilton, Coventry, England CV79JY

Phone: +44 (0) 2476 614700

Fax: +44 (0) 2476 614710

Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044

©Premier Mounts 2009

9531-017-011-00

Page 2 Installation Instructions

Table of Contents

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS

PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED

ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS,

ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELAT-

ING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.

THE WALL STRUCTURE MUST BE CAPABLE OF SUPPORTING AT LEAST 5 TIMES THE WEIGHT OF THE FLAT PANEL. IF

NOT, THE WALL STRUCTURE MUST BE RE-INFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE

TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD

RESULT IN SERIOUS PERSONAL INJURY, OR EVEN DEATH.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF THIS PRODUCT. USE PROPER

SAFETY GEAR AND TOOLS FOR THE INSTALLATION PROCEDURE TO PREVENT PERSONAL INJURY.

Warning Statements

Indicates that the power plug is to be disconnected

from the power outlet.

Safety precautions must be taken at all times.

Warning and Caution statements.

Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to do so could result in damage to the ﬂ at panel

and/or damage to the mounting surface.

Do not install near heater, ﬁ replace, direct sunlight, air conditioning or any other source of direct heat energy. Failure to do so may result in

damage to the ﬂ at panel and could increase the risk of ﬁ re.

At least two qualiﬁ ed people should perform the installation procedure. Injury and/or damage can result from dropping or mishandling the

ﬂ at panel.

Contact Premier Mounts with any questions -

(800) 368-9700.

Warning Statements 2

Parts List 3

Installation Tools 3

FLIP Mount Location 4

Hardwood Cabinet Installation 5

Softwood Cabinet Installation 6

Mount Installation - Wall Surface (Optional) 7

Attaching the Flat Panel 8

FLIP Mount Adjustments 9

Final Adjustments 9

Technical Speciﬁ cations 10

Warranty 11

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND

COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND

PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE

REFERENCE.

It is recommended that a maximum of 5/8” plaster board be used when mounting to wooden studs.

FLIP Mount

Produkt Specifikationer

Mærke:	Premier Mounts
Kategori:	Flad panel støtte
Model:	FLIP-B
Vægt:	1400 g
Produktfarve:	Sort
Panel montering grænseflade:	50 x 50, 75 x 75, 100 x 100 mm
Monteringstype:	Loft
Rotationsvinkel:	360 °
Maksimal vægtkapacitet:	9.1 kg
Maksimal skærmstørrelse kompatibilitet:	24 "
Antal understøttede skærme:	1
Minimal skærmstørrelse kompatibilitet:	10 "
Montering interface kompatibilitet (min.):	50 x 50 mm
Montering interface kompatibilitet (maks.):	100 x 100 mm
