INSTALLATION INSTRUCTIONS

PRC

LCD Ceiling Mount

NORTH AMERICA EUROPE

AUSTRALIA, NEWZEALAND,

OCEANIA (DISTRIBUTOR)

3130 East Miraloma Avenue

Anaheim, CA 92806 USA

USA and Canada –

Phone: 800-368-9700

Fax: 800-832-4888

Swallow House,

Shilton Industrial Estate,

Shilton, Coventry, England CV79JY

Phone: +44 (0) 2476 614700

Fax: +44 (0) 2476 614710

P.O. Box 295

Mordialloc Victoria 3195

Australia

Phone: 03 9586 63 30

www.premiermounts.com.au

Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044

©Premier Mounts 2008

PRC

Page - 2 - Installation Manual

Table of Contents

Parts List ............................................................................................................................................................- 3 -

Installation Tools ...............................................................................................................................................- 3 -

AST-2446 Installation ........................................................................................................................................- 5 -

PRC Installation .................................................................................................................................................- 6 -

Display Installation ............................................................................................................................................- 6 -

UFP-220 Adapter Plate (Optional Installation) .................................................................................................- 7 -

Tension Adjustment ...........................................................................................................................................- 7 -

Technical Specications ....................................................................................................................................- 7 -

Warranty ............................................................................................................................................................- 8 -

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS

PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY

UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS,

DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF

OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.

THE CEILING STRUCTURE MUST BE CAPABLE OF SUPPORTING AT LEAST FIVE TIMES THE MONITORS WEIGHT.

IF NOT, THE WALL STRUCTURE MUST BE REINFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED

SERVICE TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE

TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY, OR EVEN DEATH.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF THIS PRODUCT. USE

PROPER SAFETY GEAR AND TOOLS FOR THE INSTALLATION PROCEDURE TO PREVENT PERSONAL INJURY.

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND

COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL

INJURY AND PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE

LOCATION FOR FUTURE REFERENCE.

Indicates that the power plug is to be disconnected from the

power outlet.

Contact Premier Mounts with any questions –

(800) 368-9700.

Safety precautions must be taken at all times.

Warning and Caution statements.

Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to do so could result in damage to the flat panel

display and/or damage to the mounting surface.

Do not install near heater, fireplace, direct sunlight, air conditioning or any other source of direct heat energy. Failure to do so may result in

damage to the flat panel display and could increase the risk of fire.

At least two qualified people should perform the installation procedure. Injury ndling the and/or damage can result from dropping or misha

flat panel display.

Produkt Specifikationer

Mærke:	Premier Mounts
Kategori:	Flad panel støtte
Model:	PRC
Produktfarve:	Sort
Panel montering grænseflade:	75 x 75,100 x 100,200 x 200 mm
Monteringstype:	Loft
Fjernbetjent:	Ingen
Højdejustering:	Ja
Hældningsvinkelområde:	-15 - 15 °
Rotationsvinkel:	360 °
Maksimal vægtkapacitet:	22.7 kg
Pivot vinkel:	-15 - 15 °
Højdejusteringsområde:	838 - 1270 mm
Justerbar:	Ja
Antal understøttede skærme:	1
Montering interface kompatibilitet (min.):	75 x 75 mm
Montering interface kompatibilitet (maks.):	200 x 200 mm
