Side 1/2

Installation

Model No.

Material

Pin definition

Included Parts

Watt

Tandem limits

Length

▓ Displays any color by use of an addressable RGB LED control box or capable motherboard

▓ Built-in magnetic strip and adhesive tape provides more installation freedom

▓ Supports daisy chaining multiple light strips

LED strip is a must have for any enthusiast looking to brighten up their PCs. SilverStone created

the LS03, an addressable RGB LED strip which allows for control of each individual LED to display

colors independently for nearly unlimited combination of colors and gradients. It can be controlled

by hardware or software that can manipulate +5V, D, G, signals such as addressable RGB LED

control box or motherboard to display user’s desired colors on each LED. It also has the ability to

daisy chain multiple light strips to accommodate various applications. Finally, to improve ease of

installation and replacement, the LS03 has both built-in magnetic strip and adhesive tape to better

meet the demand of enthusiasts that require more flexibility in installation.

* Please check the control box and motherboard pin header that you want to connect are the same as LS03’s pin definition.

** Included Motherboard connect cable supports SilverStone’s addressable RGB 3pin connectors and other market standard

addressable RGB 3pin (three pin in four pin housing) connectors.

SST-LS03

12 pcs addressable RGB LED with magnetic strip and adhesive tape

+5V, D, G*

+5V, D, NP, G*

Addressable RGB LED strip x 1

Motherboard connect cable x 1**

Splitter cable x 1

3W (5V, 0.6A)

Depend on controller

300mm

Specifications

Special Features

Introduction

Для установки LS03 в корпус или на другие

поверхности используйте магнитную или

клейкую полосы на задней стороне

светодиодной ленты

利用背面磁條或是背膠將燈條固定於所欲安裝

的位置

利用背面磁条或是背胶将灯条固定于所欲安装

的位置

背面のマグネットストリップまたは粘着テープ

を使用して、LS03インストールしたい箇所へ固

定します

뒷면의 자석 스트립이나 접착 테이프를 사용하여

LS03를 설치하려는 위치에 부착하십시오

Use the magnetic stripe on the back or the

adhesive strip to affix LS03 to the location you

wish to install

Befestigen Sie den LS03 mit dem rückseitigen

Magnetstreifen oder dem Klebeband an der

gewünschten Position

Utilisez la bande magnétique au dos ou le ruban

adhésif pour fixer le LS03 à l'endroit où vous

souhaitez l'installer

Use la cinta magnética en la parte posterior ó la

cinta adhesiva para fijar la LS03 al lugar donde

desee instalarla

Utilizzare la striscia magnetica sul retro o la striscia

adesiva per fissare LS03 sul punto di installazione

Use the included extension cable to connect LS03

to motherboard, control box, or other compatible

devices

Verbinden Sie den LS03 über das mitgelieferte

Verlängerungskabel mit Motherboard, Steuerbox

oder anderen kompatiblen Geräten

Utilisez le câble d'extension inclus pour raccorder

le LS03 à une carte mère, un boîtier de commande

ou d'autres appareils compatibles

Use el cable de extensión incluido para conectar la

LS03 a la placa base, caja de control u otro

dispositivo compatible

Utilizzare la prolunga in dotazione per collegare

LS03 a scheda madre, box di controllo o altri

dispositivi compatibili

Используйте входящий в комплект кабель-

удлинитель для подключения LS03 к материнской

плате, блоку управления или другим совместимым

устройствам

使用內附的延長線連接燈條與主機板或是控制盒等訊號

源裝置

使用内附的延长线连接灯条与主板或是控制盒等讯号

源装置

LS03をマザーボード、コントロールボックス、または

その他互換デバイスに接続する際は、付属の延長ケー

ブルをご使用ください

포함된 연장 케이블을 사용하여 LS03를 마더보드,

컨트롤 박스 또는 기타 호환되는 장치에 연결하십시오

Produkt Specifikationer

Mærke:	Silverstone
Kategori:	Computertaske
Model:	LS03
Type:	Universal stribelys
Antal pr. pakke:	2 stk
Produktfarve:	Sort
Strømforbrug (maks.):	5 W
Strømkilde type:	DC
Monteringstype:	Selvklæbende tape/magnetisk montering
Understøttet placering:	Indendørs
Lysfarve:	Blue, Green, Red
Længde:	300 mm
Egnet til lys type:	Atmosfære
Antal lyskilder:	12 pære(r )
