© Copyright 2010 Smart-AVI, All Rights Reserved
Notice
The information contained in this document is
subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or
for incidental or consequential damages in connection
with the furnishing, performance or use of this material.
No part of this document may be photocopied,
reproduced or translated into another language with
out prior written consent from Smart-AVI.
HDMI Extender
HDX-100
www.smartavi.com
User Manual
2840 N. Naomi Ave.
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020
HDX-100 Specications
Function/Model HDX-100
VIDEO INPUT
Bandwidth 1.65Gps
Connector HDMI Connector x1
HDMI OUTPUT DISPLAY
HDMI Connector x 1
RJ45 Jack x 1
Max. Resolution 1920 x 1200 or
480p/720i/720p/1080i/1080p
Bandwidth 1.65Gps
Storage
Temperature
-20˚C~60˚C
Power adaptor PS5VDC1A
Housing Metal
Dimension(mm) 2.75”W x 3.875”L x 1”H
TECHNICAL SPECIFICATIONS
HDMI Extender over CAT6 STP
150 Feet over CAT6 STP
HDX-TX100
HDMI Source HDX-RX100
Qty Description Part Number
1HDX Transmitter, HDMI over
CAT6 STP Cable HDX-TX100
1HDX Receiver, HDMI over
CAT6 STP Cable HDX-RX100
1 PowerSupply5V1A PS5VD3AUS
WHAT’S IN THE BOX?
Please check the contents of the package before beginning
installation.
INSTALLATION AND OPERATION
Connecting the Splitter/Extender:
1. Connect the HDX-100 to the Component/TV/Monitor
with HDMI cable (included with the unit).
2. Connect HDX-TX100 to HDX-RX100 via CAT6 STP.
3. Connect HDX-RX100 to display.
4. Connect the power.
• Compact Transmitter/Receiver Units
• Local HDMI Output
• Perfect Image Quality at all Resolutions
(1920 x 1200, 480p, 720i, 720p, 1080i, 1080p)
• Video Resolutions up to 1920 x 1200 at 60H
(1280 x 1024 at 75Hz) on all Distances to the
Maximum Limit
• Bandwidth to 1.65Gps
• Unit Operates Regardless of Local Monitor
Connectivity
• Distances up to 150 Feet using CAT6 STP Cabling
• Compatible with all Operating Systems
• Plug-and-Play – No Software Required
FEATURES
The HDMI signal transmission unit is placed near the HDMI
source. Connect the HDMI source to the transmission unit,
which will extend the signal up to 150 feet over a single
CAT6 STP cable.
INTRODUCTION
HDX-100
Connection Diagram
