Side 1/4
Install Instructions For:
SD-250.
© 2012 MSE Audio. All rights rese ved.r PN INS-SD-250 Rev10.24.12
913.663.9770
| |
www.soliddrive.com
Faceplate
Front
Rear
Box Contents
1- Amplier
1- Stereo RCA to mini adapter
(UL 60065 compliant)
1- 32 V, 3.75 A power supply
2- Four-pin Euroblock connectors
3- Three-pin Euroblock connectors
1- Mounting bracket
SD-250
SD-250 amplier
Four-pin Euroblock
Four-pin Euroblock
Mounting bracket
Two-pin jumper block
Three-pin
Euroblock (3)
8650 College Boulevard, Overland Park, KS 66210
Three-pin Euroblock (3)
Six-pin jumper block
Warning
Avis
Les produits SD-250 doivent être installés par un intégrateur de système audio professionnel.
Pour des raisons de sécurité et de rendement audio optimal, l'installateur doit suivre toutes les
directives d'installation des produits SD-250.
SD-250 uspr u s mod ct t be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube for the SD-250.
1. Unpack amplier.
Note: Follow steps 2-5 if
using the mounting adapter.
If not skip to step 6.
2. Attach mounting bracket
to a secure pole or surface
using screws or metal
strapping.
7b. In mono mode, the left
and right inputs are
combined internally and
fed to both channels of the
amp. The left and right
channels both output the
summed signal.
7a. In stereo mode, the left
and right channels remain
separate. The amp operates
as a normal stereo amp.
6. Select stereo, bridged or
mono mode with the
included jumper.
3. To attach mounting
bracket, remove all faceplate
screws from one side. Lift
faceplate and set aside.
4. Slide mounting bracket
into groove on bottom of
amplifer enclosure.
SD-250
STEREO
Left line in
Right line in
Amp
(left)
Amp
(right)
SD-250
Left line in
Right line in
Amp
(left)
Amp
(right)
MONO
5. Replace faceplate and
screws.
Install Instructions For:
SD-250.
SD-250
Important Safety Instructions

1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade of the third prong are provided for your safety. If the
provided plug does now t into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on of pinched particularly at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11) Only use the attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
