Assembly Instructions

Lithe

Product Information

and Warnings

3453, 3454, 3456, 3458

3' Wall Lamp

4' Wall Lamp

6' Wall Lamp

8' Wall Lamp

IMPORTANT

Always disconnect the power before installing or replacing

Luminaires and before cleaning or other maintenance.

Consult a qualied, licensed electrician to ensure correct branch

circuit conductor.

Consulter un électricien qualié pour vous assurer que les

conducteurs de la dérivation sont adéquats.

Please read all included assembly instructions and warnings carefully

before installation. Contact Customer Service if you have any

questions or concerns. Before installation, please confirm that the

fixture is compatible with your supply voltage and dimming system,

if present.

LEDs are highly sensitive electronic devices, and must be treated

with care. Do not open any factory sealed compartments, and avoid

touching the LEDs with your hands or any object.

Although all our fixtures are equipped with protective devices,

LED electronic systems are vulnerable to power surges and supply

variations. Do not install LED fixtures on the same circuit as any

motors, appliances, or HVAC systems.

Do not remove or bypass any LED Driver or Transformer that is

provided with the fixture, and do not replace or substitute with

another power supply.

Fixtures must be wired in parallel on independent leads; do not

"daisy chain" multiple fixtures together or wire them in series.

All factory-made splices and connections must remain intact. LED

circuits are carefully designed and built, and improper connections

may damage the fixture.

The ends of coaxial pendant cords have been precisely stripped

and split at the factory and must not be field cut. Excess cord or

cable should be neatly coiled and reserved in the fixture canopy.

Any mounting hardware is provided for your convenience

and should be used with discretion. Always use the appropriate

hardware for the mounting surface.

Instructions D'Installation

Multiple U.S. and foreign patents pending.

Assembly Instructions

to the necessary length of black wire (not included)

to reach the xture location.

6. Feed the red and black extension wires through the

drilled hole (A).

7. Using drywall anchors and screws or other appropriate

hardware, attach the mounting plate (D) so that the

center hole of the mounting plate coincides with the

drilled hole (A) and the plate is level. Make sure the red

and black extension wires extend through the hole in

the mounting plate.

8. Using the included wire nuts, connect the positive

(red) wire to the xture's positive (+) conductor and

the negative (black) wire to the xture's negative (-)

conductor. Carefully insert these connections and any

excess wire into the wall through the drilled hole (A).

9. Fit the main xture body (C) over the mounting plate (D)

so that the tabs (F) t inside the slots in the back of the

1. Note: This xture must be installed with its power

supply in a remote, accessible location in accordance

with local electrical code.

2. Shut o power to the branch circuit.

3. Remove the xture screws (E) from the main xture body

the mounting plate (D).

4. Determine the xture location and drill a 3/4" hole (A) at

the centerpoint of the xture.

5. The power supply (B) must be installed in a remote

and accessible location near the xture location in

accordance with local electrical code (Fig. 1). Make

appropriate electrical connections:

a. Connect the power supply’s live wire to the live

supply wire.

b. Connect the power supply’s neutral wire to the

neutral supply wire.

c. Connect the power supply's postiive (+) output wire

to the necessary length of red wire (not included) to

reach the xture location.

d. Connect the power supply's negative (-) output wire

Care Instructions:

Use a clean, dry cloth when dusting.

To protect the nish, avoid any harsh

abrasives or chemicals.

Note:

• This xture is dimmable with Electronic Low Voltage (Trailing-Edge)

type dimmers, Incandescent (Leading-Edge) type dimmers, and

0-10V type dimmers only.

(C)

(A)

(D)

(F)

Fig. 1

(B)

3456

3454

3458

(E)

(F)

(E)

3453

main xture body. Re-insert and

tighten the xture screws (E).

10. Restore power to the outlet box.
