3rd Party Device

Pin 1 Left Positve (L+) ---> To ---> Left Positive (L+)

Pin 2 Left Negative (L-) ---> To ---> Left Negative (L-)

Pin 3 Ground (G) ---> To ---> Ground (G)

Pin 4

Right Positive (R+) ---> To ---> Right Positive (R+)

Pin 5

Right Negative (R-) ---> To ---> Right Negative (R-)

WyreStorm Connector

IMPORTANT! Wiring Guidelines

• The use of patch panels, wall plates, cable extenders, kinks in cables, and

electrical or environmental interference will have an adverse effect on

signal transmission which may limit performance. Steps should be taken to

minimize or remove these factors completely during installation for best

results.

• WyreStorm recommends the use of shielded category cable to minimize

signal noise and interference.

• WyreStorm recommends using pre-terminated HDMI cables due to the

complexity of these connector types. Using pre-terminated cables will

ensure that these connections are accurate and will not interfere with the

performance of the product.

RS-232 Wiring

Most control systems and computers are DTE where pin 2 is RX, this can vary from device to device. Refer to the documentation for the connected device for pin

functionally to ensure that the correct connections can be made.

Wiring and Connections

WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s

entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.

S/PDIF Port

This matrix contains audio connections for S/PDIF digital.

Audio Wiring

Devices that use a S/PDIF connection include:

MX-0404-KIT

Devices that use a Balanced Audio connection include:

MX-0808-KIT

Matrix RS-232 Port

Receiver (RX) RS-232 Port

3rd Party Device

Pin 1 TX (Transmit) ---> To ---> RX (Receive)

Pin 2 RX (Receive) ---> To ---> TX (Transmit)

Pin 3 G (Ground) ---> To ---> G (Ground)

WyreStorm Connector

3rd Party Device

Pin 2 TX (Transmit) ---> To ---> RX (Receive)

Pin 3 RX (Receive) ---> To ---> TX (Transmit)

Pin 5 G (Ground) ---> To ---> G (Ground)

WyreStorm Connector

Note: Pins not shown in table have no co nnection.

EDID Settings (MX-0404-KIT)

EDIDs can be congured to resolve issues with video output on displays that may not accept the maximum resolution available from the source.

• When set to Smart EDID (default) the matrix will scan all selected displays for the lowest resolution to dynamically adjust the source content to

allow output on 2K and 4K displays sharing the same source.

• When EDID Copy or a direct EDID is being used, SmartEDID is turned Off.

• Ensure that a display is connected and powered On to the selected output before copying EDIDs or the copy will fail. When this occurs, EDID will

be set to 4K@30Hz 2ch.

• Power to the matrix must be cycled (Off/On) after changing dip switches in order for the setting to take effect.

Accessing the Web UI

This matrix is set to a default static IP Address (192.168.11.143). In order to communicate with it initially the PC must be set to a 192.168.11.xxx address with a

subnet of 255.255.0.0. This can be changed back once a static IP is set within a different range.

1. Connect the matrix to the same network as a PC.

2. Open a web browser and enter the IP Address of the matrix

Default: 192.168.11.143 | Password: admin

IP Address Notes

• When to set to DHCP the IP address of the unit can be displayed by pressing and holding the front panel Up and Down buttons for 3 seconds. The IP address

will be displayed on the front panel.

• The installer password and general password are the same by default. WyreStorm recommends changing the password for installer login to avoid any

unwanted changes being made to the matrix conguration.

Copying EDIDs

1. Set the EDID dipswitch to the Front Panel, Web UI or API EDID

Control (all switches up).

2. Reboot the matrix.

3. Using the front navigation buttons, select the input port for the

output. Example: Input 2 for Output 2

4. Once the output port indicator blinks, press and hold Enter for 5

seconds. OK indicates that the copy was successful, FAIL indicates

that the copy failed.

5. Reboot the matrix

IR TX/RX Guidelines

• Using WyreStorm infrared emitters and receivers is the best way to ensure

that most IR coding formats are transmitted and received by the system.

Other 3rd party emitters and receivers can be used; however, these devices

must operate in the same manner as the WyreStorm devices.

• Due to differences in IR across 3rd party control systems their IR ports

should never be connected directly to a NetworkHD system as an

incompatibility may exist. WyreStorm offers a cable that compensates for

voltage differences as well adjusts for differences in the pins used within

the port. Refer to the CAB-IR-LINK product page for more information.

IR TX Port Pinout

Connection for IR TX (transmit) uses a 3.5mm (1/8in) mono plug.

IR TX Port Pinout

Connection for IR RX (receive) uses a 3.5mm (1/8in) stereo jack that outputs

+5V DC to power the included IR receiver.

Matrix Kits Full Range Quickstart Guide | 220329

2 of 4

INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)

support@wyrestorm.com

Matrix Kits Full Range Quickstart Guide | 220329

3 of 4

INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)

support@wyrestorm.com

Tip: Anode (IR Signal)

Sleeve: Cathode (GND)

Tip: Signal (+)

Shield: Ground/Return (-)

Tip:

Ring: IRSignal

+5V DC

Sleeve: Ground (GND)

Warranty Information

WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal

use for a period of ve (5) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our

limited product warranty.

EDID Switch Location

SmartEDID/Front Panel/Web UI 4K UHD 1080p

SmartEDID - Dynamic EDID

Based on Display - 2ch only

(default)

4K @30Hz (8bit only) 2ch with

HDR (SmartEDID OFF, HDCP

2.2 Support)

1080P @60Hz 2.0ch audio

(SmartEDID OFF, HDCP 1.4

Support)

Front Panel, Web UI, or API

Control

4K @30Hz 2ch with HDR

(SmartEDID OFF, HDCP 2.2

Support)

4K@30Hz 5.1ch with HDR

(SmartEDID OFF, HDCP 2.2

Support)

4K@30Hz 7.1ch with HDR

(SmartEDID OFF, HDCP 2.2

Support)

4K @60Hz 2ch

(MX-0404-HDBT-H2A-KIT)

Troubleshooting

• No or Poor Quality Picture (snow or noisy image)

• Verify that power is being supplied to the transmitter and receiving device

• Verify that all HDMI and HDBaseT connections are not loose and are

functioning properly

• Verify that the HDBaseT cable is properly terminated following EIA568B

standard

• Verify that the output resolution of the source and display is supported by

this matrix and receiver.

• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K

rated.

No or Intermittent 3rd party Device Control

Verify that the IR and RS-232 cables are properly terminated following the

Wiring and Connections section.

Troubleshooting Tips:

WyreStorm recommends using a cable tester or connecting the cable to other

devices to verify functionality.
