Side 1/2
440
White Light
TURBO
White Light
HIGH
Red Light
HIGH
White Light
MID
Red Light
MID
Red Light
LOW
White Light
LOW
White Light
LOWER
2×CR1231×18650
LUMENS
280
LUMENS
160
LUMENS
25
LUMENS
1
LUMENS
120
LUMENS
45
LUMENS
12
LUMENS
1
h
45
min
1
h
45
min
2
h
45
min
5
h
45
min
3
h
15
min
32
h
260
h
11
h
37
h
3
h
30
min
4
h
30
min
7
h
43
h
400
h
15
h
55
h
190m
(Beam Distance)
150m
(Beam Distance)
9000cd
(Peak Beam Intensity)
5700cd
(Peak Beam Intensity)
1.5m
(Impact Resistant)
IPX-8, 2m
(Waterproof AND Submersible)
440
White Light
TURBO
White Light
HIGH
Green Light
HIGH
White Light
MID
Green Light
MID
Green Light
LOW
White Light
LOW
White Light
LOWER
2×CR1231×18650
LUMENS
280
LUMENS
160
LUMENS
25
LUMENS
1
LUMENS
185
LUMENS
90
LUMENS
30
LUMENS
1
h
45
min
1
h
45
min
2
h
45
min
5
h
45
min
2
h
32
h
260
h
7
h
31
h
3
h
30
min
2
h
45
min
7
h
43
h
400
h
10
h
45
h
190m
(Beam Distance)
170m
(Beam Distance)
9000cd
(Peak Beam Intensity)
7250cd
(Peak Beam Intensity)
1.5m
(Impact Resistant)
IPX-8, 2m
(Waterproof AND Submersible)
440
White Light
TURBO
White Light
HIGH
Blue Light
HIGH
White Light
MID
Blue Light
MID
Blue Light
LOW
White Light
LOW
White Light
LOWER
2×CR1231×18650
LUMENS
280
LUMENS
160
LUMENS
25
LUMENS
1
LUMENS
35
LUMENS
15
LUMENS
3
LUMENS
1
h
45
min
1
h
45
min
2
h
45
min
5
h
45
min
2
h
32
h
260
h
8
h
33
h
3
h
30
min
2
h
45
min
7
h
43
h
400
h
11
h
45
h
190m
(Beam Distance)
66m
(Beam Distance)
9000cd
(Peak Beam Intensity)
1100cd
(Peak Beam Intensity)
1.5m
(Impact Resistant)
IPX-8, 2m
(Waterproof AND Submersible)
®
User Manual
Features
• Featuring five individual light sources: two main LEDs plus secondary red,
green and blue LEDs.
• Four selectable modes of output (red, green, blue and white)
• Dual side switches offer increased control of color modes
• Purpose-designed for law enforcement, hunting and tactical applications
• White light mode is powered by a premium CREE XP-G2(R5) LED,
providing up to 440 lumens of output
• Up to 400 hours runtime on low
• Integrated “Precision Digital Optics Technology” provides extreme reflector
performance
• Equipped with a unique multi-colored (red, green and blue) signaling mode
• Dual side switches control white and colored LEDs independently.
• Side switch features integrated power indicator light for displaying remaining
battery power (patented)
• Instant-start - enter turbo mode directly
• Physical reverse polarity protection mechanism (patented)
• Stainless steel titanium-plated clip
• Stainless steel retaining ring protects the core components from damage
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aero-grade aluminum alloy
• HAIII military grade hard-anodized finish
• Waterproof in accordance with IPX-8 (two meters submersible)
• Impact resistant to 1.5 meters
• Tail stand capability
Dimensions
Length: 143mm (5.63”)
Head Diameter: 40mm (1.57”)
Tail Diameter: 25.4mm (1”)
Weight: 138grams (4.87oz)(without battery)
Accessories
Quality holster, clip, tactical ring, lanyard, spare tail cap, spare O-ring
Optional accessories
Remote switch (RSW1), Gun Mount (GM02, GM03, GM04)
Battery Options
Thanks for purchasing NITECORE!
Brightness & Runtime
The All-Round Flashlight Expert
Operation Instructions
Battery Installation
Insert one 18650 battery or two CR123 / RCR123 batteries with the positive
pole pointing forward (toward the light head).
NOTICE
The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1 using one x 3.7V 2600mAh
Nitecore 18650 battery and 2 x 3V 1550mAh Nitecore CR123 batteries under
laboratory conditions. The data may vary slightly during real-world use due to
battery type, individual usage habits and environmental factors.
NITECORE (SYSMAX) is a member of PLATO, participating in and helping to
develop the ANSI FL1 standard of measurement. Product testing data is in
accordance with these internationally recognized scientific standards.
SIZE
Nominal voltage
Compatible
Primary Lithium battery
CR123 3V
Y (Recommended)
18650 Rechargeable Li-ion battery
18650 3.7V
Y (Recommended)
Rechargeable Li-ion battery
RCR123 3.7V
Y
CR6, CG6, CB6
CR6: Main red light mode is powered by a premium CREE XP-E(R2) LED
CG6: Main green light mode is powered by a premium CREE XP-E(G2) LED
CB6: Main blue light modes is powered by a premium CREE XP-E(D4) LED
WARNING
1. Ensure batteries are inserted with the positive (+) end pointing to the head.
The Chameleon will not operate with incorrectly inserted batteries.
2. Ensure when turning the Chameleon on, the beam is directed away from
the eyes of people or animals.
Momentary Illumination
Momentary illumination can be achieved by switching off the flashlight and
then half pressing and holding the tail switch. Simply release the switch to
turn the light off.
Switching ON/OFF
To switch ON: Press the button on the tailcap until a “click” is heard.
To switch OFF: Press the button on the tailcap a second time until a “click” is
heard.
Brightness Selection
Two side switches control the two main LEDs as well as strobe / SOS modes.
With the light turned on at the tailcap, press the left switch repeatedly to cycle
though the following WHITE LED brightness levels: ultra-low, low, medium,
high and turbo. Once a desired setting is displayed, it will be saved by turning
the light off at the tail switch.
With the light turned on at the tailcap, press the right switch repeatedly to
cycle though the following COLORED LED brightness levels: main color low
-> main color medium -> main color high -> secondary red -> secondary
green -> secondary blue. Once a desired setting is displayed, it will be saved
by turning the light off at the tail switch.
Instant High Mode
With the light turned off, press and hold the side control switch all the way
down then press the tail switch to go directly to turbo or high (main color)
mode. This feature will assist in directly switching to the highest modes of
output for emergency situations.
NOTE: When using two CR123 batteries, the light will automatically lower its
output after 20 minutes to prevent overheating and battery damage.
Strobe, Beacon and Signal Modes
With the light turned on, press and hold the left (white) switch all the way
down for more than 1 second to cycle through the following modes: strobe
mode -> location beacon -> SOS.
With the light turned on, press and hold the right switch (colored) all the way
down for more than 1 second to active police warning signal. Press the switch
again to turn this mode off.
NOTE: Among all special modes, only strobe mode can be saved.
Power Tips
1. With the light switched on, the power indicator on brightness adjustment
button will blink once every two seconds when power levels reach 50%.
2. With the light switched on, the power indicator on brightness adjustment
button will blink rapidly when power levels are low.
Changing Batteries
When the power indicator blinks rapidly this indicates the batteries need to be
replaced. Alternatively if the light becomes dim or unresponsive to adjustment
this also indicates batteries need to be replaced.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.
Warranty Service
All NITECORE
®
products are warranted for quality. DOA / defective products
can be exchanged for replacement through a local distributor/dealer within the
14 days of purchase. After 14 days, all defective / malfunctioning
NITECORE
®
products will be repaired free of charge for a period of 18
months from the date of purchase. After 18 months, a limited warranty
applies, covering the cost of labor and maintenance, but not the cost of
accessories or replacement parts. The warranty is nullified in all of the
following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE
®
products and services, please
contact your national NITECORE
®
distributor or send an email to
service@nitecore.com
The Nitecore official website shall prevail in case of any product data changes.
Features
• Featuring five individual light sources: two main LEDs plus secondary red,
green and blue LEDs.
• Four selectable modes of output (red, green, blue and white)
• Dual side switches offer increased control of color modes
• Purpose-designed for law enforcement, hunting and tactical applications
• White light mode is powered by a premium CREE XP-G2(R5) LED,
providing up to 440 lumens of output
• Up to 400 hours runtime on low
• Integrated “Precision Digital Optics Technology” provides extreme reflector
performance
• Equipped with a unique multi-colored (red, green and blue) signaling mode
• Dual side switches control white and colored LEDs independently.
• Side switch features integrated power indicator light for displaying remaining
battery power (patented)
• Instant-start - enter turbo mode directly
• Physical reverse polarity protection mechanism (patented)
• Stainless steel titanium-plated clip
• Stainless steel retaining ring protects the core components from damage
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aero-grade aluminum alloy
• HAIII military grade hard-anodized finish
• Waterproof in accordance with IPX-8 (two meters submersible)
• Impact resistant to 1.5 meters
• Tail stand capability
Dimensions
Length: 143mm (5.63”)
Head Diameter: 40mm (1.57”)
Tail Diameter: 25.4mm (1”)
Weight: 138grams (4.87oz)(without battery)
Accessories
Quality holster, clip, tactical ring, lanyard, spare tail cap, spare O-ring
Optional accessories
Remote switch (RSW1), Gun Mount (GM02, GM03, GM04)
Battery Options
Brightness & Runtime
Operation Instructions
Battery Installation
Insert one 18650 battery or two CR123 / RCR123 batteries with the positive
pole pointing forward (toward the light head).
NOTICE
The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1 using one x 3.7V 2600mAh
Nitecore 18650 battery and 2 x 3V 1550mAh Nitecore CR123 batteries under
laboratory conditions. The data may vary slightly during real-world use due to
battery type, individual usage habits and environmental factors.
®
The All-Round Flashlight Expert
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address： Rm1407-08, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
Please follow our facebook for more info: NITECORE Flashlights
WARNING
1. Ensure batteries are inserted with the positive (+) end pointing to the head.
The Chameleon will not operate with incorrectly inserted batteries.
2. Ensure when turning the Chameleon on, the beam is directed away from
the eyes of people or animals.
Momentary Illumination
Momentary illumination can be achieved by switching off the flashlight and
then half pressing and holding the tail switch. Simply release the switch to
turn the light off.
Switching ON/OFF
To switch ON: Press the button on the tailcap until a “click” is heard.
To switch OFF: Press the button on the tailcap a second time until a “click” is
heard.
Brightness Selection
Two side switches control the two main LEDs as well as strobe / SOS modes.
With the light turned on at the tailcap, press the left switch repeatedly to cycle
though the following WHITE LED brightness levels: ultra-low, low, medium,
high and turbo. Once a desired setting is displayed, it will be saved by turning
the light off at the tail switch.
With the light turned on at the tailcap, press the right switch repeatedly to
cycle though the following COLORED LED brightness levels: main color low
-> main color medium -> main color high -> secondary red -> secondary
green -> secondary blue. Once a desired setting is displayed, it will be saved
by turning the light off at the tail switch.
Instant High Mode
With the light turned off, press and hold the side control switch all the way
down then press the tail switch to go directly to turbo or high (main color)
mode. This feature will assist in directly switching to the highest modes of
output for emergency situations.
NOTE: When using two CR123 batteries, the light will automatically lower its
output after 20 minutes to prevent overheating and battery damage.
Strobe, Beacon and Signal Modes
With the light turned on, press and hold the left (white) switch all the way
down for more than 1 second to cycle through the following modes: strobe
mode -> location beacon -> SOS.
With the light turned on, press and hold the right switch (colored) all the way
down for more than 1 second to active police warning signal. Press the switch
again to turn this mode off.
NOTE: Among all special modes, only strobe mode can be saved.
Power Tips
1. With the light switched on, the power indicator on brightness adjustment
button will blink once every two seconds when power levels reach 50%.
2. With the light switched on, the power indicator on brightness adjustment
button will blink rapidly when power levels are low.
Changing Batteries
When the power indicator blinks rapidly this indicates the batteries need to be
replaced. Alternatively if the light becomes dim or unresponsive to adjustment
this also indicates batteries need to be replaced.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.
Warranty Service
All NITECORE
®
products are warranted for quality. DOA / defective products
can be exchanged for replacement through a local distributor/dealer within the
14 days of purchase. After 14 days, all defective / malfunctioning
NITECORE
®
products will be repaired free of charge for a period of 18
months from the date of purchase. After 18 months, a limited warranty
applies, covering the cost of labor and maintenance, but not the cost of
accessories or replacement parts. The warranty is nullified in all of the
following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE
®
products and services, please
contact your national NITECORE
®
distributor or send an email to
service@nitecore.com
The Nitecore official website shall prevail in case of any product data changes.

Produkt Specifikationer

Mærke: Nitecore
Kategori: Lommelygte
Model: CR6

Har du brug for hjælp?

Hvis du har brug for hjælp til Nitecore CR6 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Lommelygte Nitecore Manualer

Nitecore

Nitecore Chameleon CU6 Manual

27 September 2025
Nitecore

Nitecore SRT7 Revenger Manual

27 September 2025
Nitecore

Nitecore T360 Manual

27 September 2025
Nitecore

Nitecore CR6 Manual

27 September 2025
Nitecore

Nitecore MH40 Manual

27 September 2025
Nitecore

Nitecore i4000R Manual

27 September 2025
Nitecore

Nitecore T5s Manual

27 September 2025
Nitecore

Nitecore T360M Manual

27 September 2025
Nitecore

Nitecore EC21 Manual

27 September 2025
Nitecore

Nitecore P18 Manual

27 September 2025

Lommelygte Manualer

Nyeste Lommelygte Manualer

Draper

Draper Expert 65690 Manual

24 September 2025
Draper

Draper Expert 31097 Manual

23 September 2025
Draper

Draper Expert 30986 Manual

23 September 2025
Nextorch

Nextorch MyTorch S2AA Manual

20 September 2025
Milwaukee

Milwaukee FL-LED Manual

16 September 2025
Klein Tools

Klein Tools 56308 Manual

15 September 2025
Zweibrüder

Zweibrüder LED Lenser F1R Manual

12 September 2025
Zweibrüder

Zweibrüder LED Lenser M7R Manual

12 September 2025
Zweibrüder

Zweibrüder LED Lenser SEO 7R Manual

12 September 2025
Zweibrüder

Zweibrüder LED Lenser F1 Manual

12 September 2025
