User Manual

The All-Round Flashlight Expert

MH10

Features

·Utilizes a CREE XM-L2 U2 LED

·Maximum output of up to 1000 lumens

·Integrated “Precision Digital Optics Technology” provides extreme reflector

performance

·Boasts a peak beam intensity of 13,500 cd and a throw distance of up to 232

meters

·Innovative single button offers access to four brightness levels and three special

modes

·High efficiency constant current circuit provides max runtime of 520 hours

·Integrated power indicator light displays remaining battery power (Chinese Patent:

ZL201220057767.4 )

·Power indicator’s secondary function displays battery voltage (accurate to 0.1V)

·Charging module with a micro USB port charges Li-ion batteries rapidly

·Direct access to ultra-low output

·Reverse polarity protection prevents damage from incorrectly inserted batteries

·Constructed from aero grade aluminum alloy with HAIII military grade

hard-anodized finish

·Waterproof in accordance to IPX-8 (two meters submersible)

·Impact resistant to 1.5 meters

·Tail stand capability

Dimensions

Length: 130mm (5.12”)

Head diameter: 25.4mm (1”)

Tube diameter: 25.4mm (1”)

Weight: 75g (2.65oz)(without battery)

Direct access to ultra-low

With the MH10 switched off, press and hold the switch for more than 1 second to

enter ultra-low output (1 lumen);

Note: When in high output, the MH10 will reduce output luminance automatically after

5 minutes of use to prevent overheating and extend battery longevity.

Special Modes (Strobe/SOS/Location Beacon)

Press the switch twice in quick succession in any state to enter strobe mode. When in

strobe mode, press and hold the switch for more than 1 second to cycle through SOS,

location beacon and strobe modes. To exit, simply press the switch again. The MH10

does not have memory effect in any of these special modes.

Charging Function

The MH10 is capable of charging one 18650 Li-ion battery with the included USB

charging cable. Connect the USB cable to the MH10's charging port and a power

source (USB chargers, PC or other power terminals) as shown in the adjacent image.

Fully charging one depleted 18650 battery takes approximately 6 hours.

Thanks for purchasing NITECORE!

Output & Runtime

NOTICE

The stated data has been

measured in accordance with

the international flashlight

testing standards ANSI/NEMA

FL1, using 1xNitecore 18650

battery (3.7V, 2600mAh) or

2xNitecore CR123 batteries

(3V, 1700mAh) under

laboratory conditions. The data

may vary in real-world use due

to different battery use or

environmental conditions.

TYPE

Nominal voltage

Compatible

Primary Lithium battery

CR123 3V

Y (Recommended)

18650 Rechargeable Li-ion battery

18650 3.7V

Y (Recommended)

Rechargeable Li-ion battery

RCR123 3.7V

Operating Instructions

Battery Installation

Insert 1x18650 battery or 2xCR123

batteries as illustrated.

Note: After loading batteries, the blue

power indicator will blink to indicate battery

voltage.Please refer to “Power Tips”

section of this manual for details.

WARNING

1. Ensure batteries are inserted with the

positive (+) ends pointing to the head. The

MH10 will not be operational with

incorrectly inserted batteries.

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Rm1401-03, Glorious Tower, 850 East Dongfeng Road,

Guangzhou, China 510600

20150916

Changing /Charging Battery

Batteries should be recharged or replaced when any of the followings occurs: The

power indicator blinks rapidly, output appears to be dim or the flashlight becomes

unresponsive.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin coating

of silicon-based lubricant.

Warranty Service

All NITECORE® products are warranted for quality. Any defective / malfunctioning

NITECORE® product can be repaired free of charge for a period of 60 months (5 years) from

the date of purchase. Beyond 60 months (5 years), a limited warranty applies, covering the

cost of labor and maintenance, but not the cost of accessories or replacement parts.

The warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE® products and services, please contact a local

NITECORE® distributor or send an email to service@nitecore.com

※All images, text and statements specified herein this user manual are for reference purpose

only. Should any discrepancy occurs between this manual and information specified on

www.nitecore.com, information on our official website shall prevail. Sysmax Industry Co., Ltd.

reserves the rights to interpret and amend the content of this document at any time without

prior notice.

4.2V3.5V 3.7V 3.9V

Full powerLow power

6.4V4.8V 5.6V 6.0V

Full powerLow power

1 x 18650 battery

2 x CR123 batteries

HIGH MID LOW

LUMENS

240

LUMENS

1000

LUMENS

LUMEN

min

LOWER

520

min

300

232m

(Beam Distance)

13500cd

(Peak Beam Intensity)

IPX-8, 2m

(Waterproof AND Submersible)

1.5m

(Impact Resistant)

1×18650 2×CR123

Accessories

Nitecore NL183 battery, USB charging cable,

holster, clip, lanyard, spare USB port cover,

spare O-ring

Battery Options

2. When the MH10 is kept in a backpack or left unused for extended periods of time,

Nitecore recommends all batteries are removed to prevent accidental activation of the

flashlight or battery leakage.

ON/OFF

To switch ON: Press the switch until a click is heard.

To switch OFF: Press the switch once again until a click is heard.

Brightness Levels

With the MH10 switched on, press and hold the switch for more than 0.5 second to

cycle through brightness levels of ultra-low, low, medium and high. To select a desired

brightness level, simply release the switch when that level is being displayed. This

mode has memory effect to ensure direct access to the previously used brightness

level when the MH10 is resumed.

Under normal charging conditions, the blue power indicator light will illuminate

steadily to notify users. When charging is complete, the MH10 will terminate the

charging process automatically and the blue power indicator goes out.

Power Tips

1. When the light is on, the power indicator will blink once every two seconds when

power level drops to 50%; the power indicator will blink quickly when power level is

low.

2. After battery installation, the blue power indicator will blink to indicate battery

voltage (accurate to 0.1V). For example, when battery voltage is at 4.2V, the blue

power indicator will blink 4 times, followed by a one second pause and another 2

blinks. Different voltages represent the corresponding remaining battery power levels:

Please find us on facebook:

NITECORE Flashlights

Produkt Specifikationer

Mærke:	Nitecore
Kategori:	Lommelygte
Model:	MH10
Bredde:	130 mm
Vægt:	75 g
Produktfarve:	Sort
Lampe type:	LED
Batterilevetid (maks.):	520 t
Batteritype:	18650/CR123
Antal lamper:	1 Lampe( r)
Lysfarve:	Hvid
Lommelygte type:	Hånd lommelygte
Lysstråle afstand (maks.):	232 m
Lommelygte tilstande:	SOS mode, Strobe mode
Lysstrøm:	1000 lm
LED type:	CREE XM-L2 U2
Lysstyrke:	13500 Candella
Hoved, diameter:	25.4 mm
