TM 06

Features

· The world’s smallest and lightest 3800lm flashlight

· Utilizes four CREE XM-L2 U2 LEDs

· Features advanced temperature regulation (ATR) technology

· Tactical forward switch on the tail cap

· Innovative two stage side switch accesses different modes and

functions (patented)

· Integrated power indicator on side switch indicates remaining battery

power (patented)

· Power indicator displays battery voltage accurate to 0.1V

· Direct access to ultra-low or turbo output

· Toughened ultra-clear mineral glass with anti-reflective coating

· Integrated “Precision Digital Optics Technology” provides extreme

reflector performance

· Stainless steel bezel ring protects core components from damage

· Constructed from aerospace grade aluminum alloy

· HAIII military grade hard-anodized

· Waterproof in accordance with IPX-8 (submersible to 2 meters)

Dimensions

Length: 4.92” (125mm)

Head diameter: 1.97” (50 mm)

Tube diameter: 1.97” (50mm)

Weight: 9.77oz (277 gram) (without battery)

Battery Options

NOTE: After loading the batteries, the power indicator light will blink to

indicate the battery voltage. Please refer to the “Power Tips” section of

this manual for details

WARNING:

1. Insert batteries as labelled on the inside of the battery compartment.

2. Do not mix batteries of different types/brands.

3. When the TM06 is stored in a backpack or left unused for extended

periods, Nitecore recommends the tailcap is loosened to cut off the power

entirely, thus preventing accidental activation of the flashlight.

Momentary Illumination

Press the tail switch partway to turn the light on, simply release to turn off

Constant Illumination

To turn on: press the tail switch until a “click” is heard

To turn off: press the tail switch again until a “click” is heard to turn the

light off and enter standby mode

Standby mode: When in standby mode, press the side switch all the way

down to activate the power indicator to flash once every three seconds,

thus helping users locate the flashlight in dark conditions. In standby

mode, the TM06 will operate for up to 30 days with the power indicator on

and up 108 days with the power indicator off.

Brightness Levels

The TM06 utilizes a 2-stage switch similar to a camera shutter button. The

light’s numerous functions are selected according to the depth the switch

is pressed.

With the light turned on, press the side switch all the way down repeatedly

to cycle through ultra-low, low, medium, high and turbo brightness levels.

Alternatively, with the light turned on, press the side switch partway to

adjust the brightness levels in reverse until ultra-low output is displayed.

Note: When in ultra-low/low/medium/high mode, press and hold the side

switch partway down for more than one second will access turbo mode.

Instant ultra-low/turbo

When in standby mode, press the tail switch while holding the side switch

partway down to enter ultra-low mode (3 lumens).

When in standby mode, press the tail switch while holding the side switch

all the way down to enter turbo mode (3800 lumens)

Special Modes (Strobe/Location

Beacon/SOS)

With the light turned on, press and hold the side switch for more than one

second to enter Strobe mode. To cycle through SOS, Location Beacon and

Strobe modes, simply press and hold the side switch for more than one

second once again. To exit special mode and resume the previously used

output, simply press the side switch again.

NOTE: The TM06’s memory function offers direct access to the previously

used brightness when reactivated.

Power Tips

1. With the light turned on, the blue LED built into the switch will flash

once every two seconds when battery power levels reach 50%. The blue

LED will flash quickly when battery power is close to depletion.

2. Each time batteries are inserted, the power indicator light will blink in

varying patterns to indicate battery voltage (accurate to ±0.1V). For

example, when battery voltage is at a maximum charge of 4.2V, the power

indicator will blink 4 times in quick succession, followed by a one second

pause, and then two more blinks, thus indicating the battery voltage

detected is 4.2V. Different voltages represent the corresponding remaining

battery power levels:

NITECORE (SYSMAX) is a member of PLATO, participating in and

helping to develop the ANSI FL1 standard of measurement. Product

testing data is in accordance with these internationally recognized

scientific standards.

NOTICE:

The above data has been measured in accordance with the international

flashlight testing standards ANSI/NEMA FL1 using 4 x 3.7V 2600mAh

18650 batteries under laboratory conditions. The data may vary slightly

during real-world use due to battery type, individual usage habits and

environmental factors.

ATR Technology

Advanced temperature regulation (ATR) technology allows the TM06 to

dynamically adjust output performance according to its body temperature.

This prevents damage from overheating and prolongs its working life.

Changing/Charging Batteries

Batteries should be replaced when any of the following occurs: The

power indicators blinks rapidly, output appears to be dim or the flashlight

becomes unresponsive.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a

thin coating of silicon-based lubricant.

Warranty Service

All NITECORE® products are warranted for quality.Any DOA / defective

product can be exchanged for a replacement through a local

distributor/dealer within 15 days of purchase. After 15 days, all defective /

malfunctioning NITECORE® products will be repaired free of charge for a

period of 60 months (5 years) from the date of purchase. Beyond 60

months (5 years), a limited warranty applies, covering the cost of labor

and maintenance, but not the cost of accessories or replacement parts.

The warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE® products and services, please

contact your national NITECORE® distributor or send an email to

service@nitecore.com

The Nitecore official website shall prevail in case of any product data

changes.

Operating Instructions

Battery installation

1. Insert batteries with the positive (+) and negative (-) ends

corresponding to the diagram on the inside of the battery compartment.

2. Tighten the tail cap by aligning the two metal pins on the inside of the

tail cap with the corresponding holes on the flashlight body and rotate

clockwise.

*Warning: Do not use the TM06 with RCR123 or CR123 batteries for it

may damage the flashlight.

Output & Runtime

Accessories

Quality holster, lanyard,

spare O-ring

TURBO

HIGH MID LOW LOWER

LUMENS

3800

LUMENS

1500

LUMENS

480

LUMENS

160

LUMENS

45min 9h 25h 433h

h15min

334m (Beam Distance)

28000cd (Peak Beam Intensity)

1.5m (Impact Resistant)

IPX-8, 2m

(Waterproof AND Submersible)

Thanks for purchasing NITECORE!

User Manual

The All-Round Flashlight Expert

SIZE

Nominal voltage

Compatible

Primary Lithium battery

CR123 3V NO

18650 Rechargeable Li-ion battery

18650 3.7V

Yes (Recommended and

can be recharged)

Rechargeable Li-ion battery

RCR123

3.7V NO

NOTE: When a detected battery is not of the 18650 type, the power

indicator light will blink rapidly to notify the user.
