NOTICE

The information contained in this document

is subject to change without notice. SmartAVI

makes no warranty of any kind with regard to

this material, including but not limited to,

implied warranties of merchantability and

fitness for particular purpose.

SmartAVI will not be liable for errors

contained herein or for incidental or

consequential damages in connection with

the furnishing, performance or use of this

material.

No part of this document may be

photocopied, reproduced, or translated into

another language without prior written

800.AVI.2131

Tel: (818) 503 6200 Fax: (818) 503 6208- -

11651 Vanowen St. North Hollywood, CA 91605

SmartAVI.com

Mini-

Mini-Mini-

XTXT

Designed and Manufactured in the USA

VGA Extender with Audio over

CAT5e/6

Quick Start Guide

Extend 1080p VGA video signals and

audio over a single CAT5e/6 cable

up to 1000 feet

VIDEO

Signal Type 1 VGA

Connection -45 (CAT5/5e/6) RJ

RX Bandwidth 150MHz 3dB @ 1500V/us —

Video Input Level +0.75Vrms

Attenuations (1) Focus, (1) Bright,

(1) Ultra Bright

TECHNICAL SPECIFICATIONS

OTHER

Power

5VDC 2A

Dimensions

2.04”W x 1.06”H x 2.55”D

Weight

0.55lbs

Humidity

0 —80%

Operang Temp.

0 —50° C

AUDIO

Stereo Connector Type 3.5 mm jack

Part No. Description

MINI-XTS VGA with Audio Extender

over Cat5e/6. Includes:

[Mini- -TX, Mini- -RX, XT XT

MINI- -TXS VGA with Audio Transmitter XT

over Cat5e/6. Includes:

[MINI- -TX XT

MINI- -RXS VGA with Audio Receiver XT

over Cat5e/6. Includes:

[MINI- -RX XT

ORDER INFO

The Mini-XT extender sends 1080p (1920x1080 @

60Hz) HD video signals from VGA sources and

stereo audio up to 1000 feet away using a single

CAT5e/6 cable. Capable of adjusting focus and

brightness of connected signals, the Mini-XT also

makes for a great optimizer tool.

FEATURES



Up to 1000 feet of signal extension



Up to 1080p resolution (1920x1080 @ 60Hz)



Internal EDID



Stereo Audio support



Single-cable CAT5e/6 signal extension



Adjustable brightness and focus control for

picture optimization



VGA, SVGA, XGA, SXGA, and Multisync monitor

support



Windows, LINUX, Mac, and Sun systems

compliant



Plug- -play ready and

CONNECTING this Product

1. Power down all devices you wish to connect.

2. Connect Mini- -TX to computer with a VGA cable. XT

3. Connect Mini- -TX to computer with stereo audio cable. XT

4. Connect Mini- -RX to output device with a VGA cable. XT

5. Connect Mini- -RX to output device with a stereo audio cable. XT

6. Connect Mini- -TX and Mini- -RX with a CAT5e/6 cable. XT XT

7. Connect DC power sources to both TX and RX.

8. Return power to your computer and connected devices.

INSTALLATION DIAGRAM

FRONT

BACK

PART NO. QTY DESCRIPTION

Mini- -S XT

1 Port VGA Extender with Audio over -

Cat5e/6 [Mini TX, Mini RX]-XT- -XT-

PS5VDC2A 2 Power Supply

Quick Start 1 Quick I nstallation guide

User Manual 1 Detailed Instruction

WHAT’S IN THE BOX
