Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343 1

Instruction Manual

Thank you for choosing this WyreStorm product.

Please read these instructions carefully before installing to avoid complications later.

Wyrestorm HDBaseTTM Class D Digital Audio Amplier / Receiver / Repeater

Part Number AMP-001-010

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Contents

1. Introduction

CONTENTS AND INTRODUCTION

AMP-001-010 Wyrestorm HDBaseTTM Class D Digital

Audio Amplier / Receiver / Extender

The Wyrestorm AMP-001-010 is a unique HDBaseT

Class D digital audio amplier with receiving and repeating

functionality that fundamentally changes the way to approach

the design of multi-room audio-visual systems.

Fully cascadable (daisy-chained) over multiple 70m/230ft

distances up to 7 times using a single Cat5e cable to create

larger distributions. It also offers HDMI/HDBaseT reception

and pass-thru, 2.1 audio amplication with subwoofer and

stereo preouts for connection to an AVR and HDMI breakout

with bidirectional control of source/display from either

location via IR/RS232.... and so much more.

Feature rich and highly versatile, the AMP simplies,

combines and improves the relationship between HDMI,

HDBaseT and stereo audio for integrators by incorporating

3:1 audio switching from centralized AV sources and ARC or

local audio input.

Introduction

Features

Safety Precautions

Package Contents

Panel Descriptions

i. Front

ii. Rear

EDID Management

i. About EDID

ii. Before EDID adjustment

iii. EDID Pre-sets

RS232 Application Scenarios

i. Understanding RS232 Connection & Signals

ii. Zonal IR for Cascading Multiple Independently

Controlled AMP units

iii. Global IR for Cascading Multiple Collectively controlled

AMP units

iv. Hybrid IR for combination of Zonal and Global IR

control of multiple AMP units

v. RS232 Addressing

vi. Routable RS232 with Wyrestorm POH-enabled

HDBaseT Matrices - MX-PP-POH

vii. Residential RS232 HDBaseT Addressing example

viii. Example system topology showing multiple, dierently

addressed amps.

ix. Commercial RS232 HDBaseT Addressing example

Specications

Basic Operation

Remote Control Handset Operation

Application Scenarios and installation benets

i. Basic Centralized Source

ii. Extended Centralized Source

iii. Basic Matrix

iv. Extended Matrix

v. AMP-001-010 as Display Receiver

vi. AMP-001-010 as In-line Solution

vii. Central Conguration

Onscreen User Interface

Connection and Operation

i. Cabling Guide

ii. RJ45 Termination

iii. Initial Connection

iv. IR/RS232 Control Connection

v. Optional Device Connection

- Personal Device Audio Input

- Speaker Connection

- Subwoofer

- External Power Amplier

- Supported Speaker Types

vi. Interface Device

Maintenance

FAQ’s

Troubleshooting

Provided Service

Mail In Service

Installation Notes

Warranty

i. Warranty Limits and Exclusions
