WyreStorm HD over IP Solutions Part Number NHD-IP-TX
NHD-IP-RX
Scalable HD Over IP Solution for
Networked Distribution using
JPEG2000 compression
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
Instruction Manual
2Technical support: support@wyrestorm.com EMEA/ROW: +44 (0) 1793 230 343
Contents
1. Introduction
CONTENTS AND INTRODUCTION
WyreStorm® NetworkHDTM is a professional grade
JPEG2000 HD over IP extender and control system
enabling the distribution of HDMI over a dedicated
IP network switch with powerful KVM and video wall
functionality designed for commercial AV applications.
Comprising of an receiver and NHD-IP-RX NHD-IP-TX
transmitter extender set together with an NHD-IP-CTL
controller, the and extenders facilitate NHD-IP-RX NHD-IP-TX
the transmission of an HDMI 1.3 signal (including Full HD
1080p video with 2.1 audio) to one or more HDMI LCD/LED
panels or digital projectors over standard Ethernet (Cat5e/6/7)
infrastructure.
The modular system architecture of NetworkHD removes the
limitations of a traditional xed platform I/O matrix system without
compromising quality or reliability, whilst oering signicant cost
savings when designing large scale infrastructure systems as well
as integrating other features such as Video Wall processing.
As simple as it is powerful, NetworkHD functions on a basic
Smart switch platform so does not require advanced integrator
Network experience to install, nor does it require a managed
network switch with VLAN congured, making it one of the
simplest HDMI over IP systems available.
Conguring network switches takes minutes and even the largest
distributions can be quickly and easily congured and expanded.
Adding transmitters and receivers as required to enable the
system to grow with the needs of the application. NetworkHD
uses Bonjour technology to automatically discover system
components to make setup a breeze.
The controller creates a simple, single interface to NHD-IP-CTL
congure, manage and control the entire NetworkHD system,
whilst also capable of fully integrating with WyreStorm Enado
control interface for the highest quality total HD distribution and
control solution over a network.
For further information on this product and other WyreStorm
ranges, visit our website or download our latest product guide.
wyrestorm.com
Introduction
Features
Safety Precautions
Package Contents
Panel Description:
i. NHD-IP-TX Transmitter
ii. NHD-IP-RX Receiver
Connection
Switch Settings and Requirements
Typical Application
i. One Transmitter to One Receiver
ii. One Transmitter to Multiple Receivers
iii. Multiple Transmitters to Multiple Receivers
iv. Video Wall
NHD-IP-CTL Browser Conguration & Control
i. Matrix Switching Commands
ii. TX/RX Settings
iii. Alias
iv. Commands
NetworkHD Console Conguration
i. NetworkHD Console Software Installation
ii. Searching Devices
iii. Setting Device Parameters
iv. Device Settings
v. Creating Scenes
vi. Sample Video Wall Set Up
vii. Video Wall Conguration
viii. Video Wall Properties
ix. Conguration File Management
x. Log
Specications
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
19
16
17
18
Troubleshooting
Additional Information
FAQ
Maintenance
Provided Service
Mail In Service
Installation Reference Logs
i. Warranty
ii. Warranty Limits and Exclusions

Produkt Specifikationer
