MODEL

48085D

Dinky Link™ Surface Mount

CFL/LCD Proof IR Receiver

INSTALLATION INSTRUCTIONS

DESCRIPTION

These small IR receivers have been designed for mounting in very small

spaces. They may be mounted under shelf edges, cabinet ledges, in wall

speakers, etc. – anywhere an inconspicuous appearance is desired.

FEATURES

• Very small package, only 2.45”L x 0.45”W x 0.35”H.

• Wire channel for clean installation.

• System testing red-talk-back LED.

• Includes 3-Terminal Block for easy extension to remote room locations.

SPECIFICATIONS

• Infrared carrier input frequency bandwidth: 30 - 60kHz.

• Reception range: Up to 50 feet, depending on conditions.

• Nominal reception angle: 55 degrees off axis.

• Cable requirements: See “INSTALLATION” below.

• Max. transmission length: 1 mile using 18 gauge wire.

• Maximum current output: 100mA

• Drives IR emitters through Xantech Connecting Blocks, Controllers, etc.

• Power requirements: +12VDC, 20mA.

3.5mm mini plug Signal Name

TIP SIGNAL

RING GROUND

SLEEVE +12VDC

INSTALLATION

QUICK-START

A typical system will use an IR receiver, several emitters, and a power supply

all connected to a connecting block.

1. Connect the IR receiver to the “IR RCVR” port on the connecting

block. The ‘red’ connector is installed to the ‘red’ plug.

Note: In some extended distances, additional 3-conductor may be required and can

be connected to the terminals on the connecting block.

2. Connect the Emitters to the connecting block. The ‘yellow’ connector

is installed to the ‘yellow’ plug.

3. Connect the power supply to the connecting block.

4. Installation complete

ADJUSTING IR CARRIER FREQUENCY

The IR receiver is factory set to an IR carrier frequency of 38kHz. This will be

correct for the majority of installations, however, some manufacturer’s

components that you wish to control may use difference carrier frequencies

(such as digital cable boxes which use carrier frequencies between 52kHz

and 56kHz). If such carrier frequencies fall within the range of 32kHz to

56kHz, you can adjust the IR receiver to match them for best range

performance. The adjustment can be made through a small opening on the

rear of the unit.

To adjust, proceed as follows:

1. First, try the IR receiver in the system. If the system controls all the

desired components with adequate range, do not make any

adjustments.

2. If the system does not work or has poor range, determine the IR

carrier frequency of the product you wish to control. Contact the

manufacturer of the product, if necessary, to determine this

frequency.

3. Using a small blade type screwdriver, rotate the adjustment shaft

slightly either clockwise to obtain carrier’s less than 38kHz or

counter-clockwise to obtain carrier’s greater than 38kHz.

4. If you have audio/video equipment in the same system that have

different IR carrier frequencies, you will have to adjust the IR receiver

to the midway position. For example, some products may operate at

38kHz and others at 56kHz. In this case, set the adjustment in

between this range so both products can operate in the system.

Note: Some products are more tolerant of compromised frequency settings than

others. You may have to “fine tune” the adjustment to “favor” the least tolerant

component for the best performance of all units in the system.

REMOTE ROOM APPLICATION

One application is to locate the IR receiver in a remote room. This will give

the end-user the ability to control audio/video equipment from a location

where the remote control no longer has the ability of direct line-of-sight.

The IR receiver will need the 3.5mm stereo type mini plug removed to extend

the wire run to the connecting block. A 3-terminal block is supplied to connect

the IR receiver to the connecting block with a 3-conductor inter-room cable in

between.

The 3-conductor inter-room cable (24 gauge up to 200’, 22 gauge up to 600’,

20 gauge up to 2000’, 18 gauge up to 5000’), is run to the main room.

While it is possible to make wired connections without the connecting block,

it is not recommended. The connecting block reduces installation time, helps

to eliminate errors, allows easy troubleshooting and permits easy system

upgrades later, if needed.

Input connections must be made as illustrated. To extend the emitter wires to

a more distant location, you may splice in 2-conductor wire, in the wire

gauges mentioned before, as needed.

LOCAL SYSTEM APPLICATION

Another application is to locate the IR receiver in a central location, such as

the TV, video screen and/or a speaker. The audio/video equipment can then

be hidden inside a cabinet or located away from the front of a room. This will

give the end-user the ability to direct a remote control to one central location

and not have to worry about aiming to the respective device to be controlled.

Since the IR receiver is in close proximity to the audio/video equipment, no

wiring extension should be required so long as the connecting block is within

reach of the 7-foot cable. The 3.5mm stereo type mini plug is connected to

the “IR RCVR” jack on the Xantech Connecting Block.
