Side 1/16
1
Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Instruction Manual
Extending 4K & 1080p HDMI
using single Cat5e/6
eX-35-4K
WyreStorm Low Prole 4K HDBaseT Extender
Set with 2-Way IR, RS232 and POH
(4K: 35m/115ft - 1080p: 70m/230ft)
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
2Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343
Contents
1. Introduction
CONTENTS, INTRODUCTION AND FEATURES
2. Features
Get Real. Think Thin.
Pushing technology and design to the limit, the EX-35-
4K extender set oers long distance HDMI 4K and HD
distribution and control over UTP within an incredibly low
prole chassis of just 15mm for a greatly reduced form
factor behind even the slimmest display wall plate to
make installation a dream.
Featuring streamlined Class B HDBaseT technology
for projects that demand the benets of HDBaseT
transmission, but perhaps do not require full Class
A specication, the EX-35-4K supports 70m/230ft
transmissions of 1080p@60Hz and 36bit Deep Color HD
Introduction
Features
Safety Precautions
Package Contents
Connection & Operation
i. Typical Application
ii. RJ45 Termination & Distance
iii. Initial Connection
iv. IR/RS232 Control Connection
v. Updating RS232 Settings
Maintenance
Product Service
Panel Descriptions
1
2
3
4
5
6
7
8
9
10
12
13
Mail In Service
Warranty
i. Warranty Limits and Exclusions
Installation Notes
Specication
Troubleshooting
General FAQ
14
11
audio, 100W power, discrete bidirectional control via IR
and RS232 all along a single Cat5e/6 cable to display
zones.
UltraHD 4K transmissions are supported up to 35m/115ft
over Cat6 at 30fps with chroma sub-sampling color
palette of 4:2:2 and automatic internal handling of EDID
and HDCP 2.2 between connected source/display
devices.
Including serial control support with compatibility with
leading control systems and switchable RS232 selection
for rmware updates, improved 18v power connectivity is
also oered via threaded DC power port for standard and
locking DC power plugs on both transmitter and receiver,
should it be required.
Operation status is illustrated by panel LED indicators for
power supply, signal status for display connection, HDCP
2.2 in signal, and a HDBaseT link indicator to assess
the presence of transmissions and help identify potential
issues.
WyreStorm 4K HDBaseT solutions oer the features,
exibility and compatibility demanded by modern
integrations while future-proong for tomorrow, combined
with an ease of use and cost-eciency for reliable
distribution and control of digital content over distance
whether in a residential or commercial setting.
For further information on this product and other
WyreStorm ranges, visit our website or download our
latest product guide. wyrestorm.com
• Low prole chassis of 15mm / 0.6” for easier, more
convenient installations behind screens at display
zones.
• Extender set capable of HDMI transmissions using
single cable Cat5e/6 cable under recommended
conditions*:
- 35m/115ft: 3840 (UHD) 4096 (DCI) 2160 4K
video/24bit True Color @30Hz with 4K Chroma
subsampling color palette 4:2:2
- 70m/230ft: 1920x1080p HD video/36bit Deep
Color@60Hz
• Transmits discrete wide-band two-way IR control
signal / serial commands together within the HDMI
signal over a single Cat5e/6
• One-way PoH (Power over HDBaseT) 18v DC locally
powered Transmitter passes power along the Cat5e/6
to remotely power the Receiver - no mains power
required at display zones
